- Page 1 4-CH Quad Video Server ACD-2000Q Ver. 081218 Quick Installation Guide...
-
Page 2: Getting Started
Getting Started PACKAGE CONTENTS ACD-2000Q Power Adaptor (Option) Terminal Blocks & Screws Product CD Warranty Card... -
Page 3: Physical Description
PHYSICAL DESCRIPTION Audio Input / Output The video server supports one audio input and output with earphone jack CAM1, CAM2, CAM3 and CAM4 Analog Video Input of Composite Signal with BNC Connectors. Action LED Indicator The LED will light up after video server has successfully completed the boot process. - Page 4 release the reset button. The unit will start up with factory default settings. Terminal Blocks Pin 1~6 The video server supports two alarm input and two alarm output. DI: Logic Level 0: 0~0.4V; Logic Level 1: 3.3~30V Logic Level 0: 0.1~0.6V; Logic Level 1: 2.4~5V Please find Support package”...
- Page 5 Dip Switch for Serial Port RS-485 or RS-422 pin define (default is RS-485) RS-232 pin define Ethernet Port The video server connects to the Ethernet via a standard RJ45 connector. Supporting NWAY, this IP device can auto detect the speed of local network segment (10Base-T/100Base-TX Ethernet).
-
Page 6: Basic Connections
BASIC CONNECTIONS Follow the procedures below to connect the video server to the respective apparatuses. Connect an analog video source (e.g. CCD Camera) to the video server’s CAM1 ~ CAM4(BNC connector). Connect the video server’s ethernet port to an Ethernet (RJ45 connectors) Connect a PC to the Ethernet hub (RJ45 connectors) Connect a power adaptor to the video server (terminal block... -
Page 7: Quick Tour
Quick Tour This section guides you with a quick tour on this IP device. 2.1 Configure this IP Device 2.1.1 Make sure network environment Default IP of this video server is 192.168.0.100. Please make sure this video server and your PC are on the same network segment before running the installation. Please set the settings as below. - Page 8 2.1.2 Open Internal Explorer with IP address STEP1: Open a browser STEP2: Enter the IP address of the video server The default IP address is “192.168.0.100” The “Login Page” is now displayed as below. STEP3: Enter the Account name (factory default: admin) and the Password (factory default: 123456).
- Page 9 STEP1: Click the [Encoder] to choose a compression mode, such as MPEG4, or MJPEG. STEP2: Click the [Audio Out] checkbox to enable/disable audio output from control PC to IP device. STEP3: Click the from [Volume] to control volume out degree control PC to IP device.
- Page 10 2.1.4 Set the new IP address *IP Address : The default IP address is 192.168.0.100. *Subnet Mask : The default subnet mask is 255.255.255.0 *Click button NOTE: In your Client PC, please make sure the setting of Network Connections Type is set to Auto Negotation, since this IP device follows MII standard.
- Page 11 2.1.5 Check Default Video Setting 2.1.6 Click Save Reboot to save all settings and please wait about 30 seconds for system reboot.
