Use this slot for manual match lighting
6
12/22/04 9:03 AM Page 6
Using the Igniter to Light the Burner
Raise the lid of the barbecue.
•
Push in and turn the control knob to "High" position.
•
Push the igniter button until a clicking noise is heard (a spark is being applied).
•
If the burner does not light after three attempts, turn the control knob
•
to the "Off " position and wait for the gas to clear (about 5 minutes).
Repeat the previous lighting procedure.
If the burner still does not light, refer to the troubleshooting guide for help,
•
or light with a long match.
Manual Lighting Procedure
The barbecue has ventilation slots on the underside of the housing. The left slot
may be used to manually light the barbecue.
Raise the lid of the barbecue.
•
Place a lighted match through the slot shown to within (15 cm) 1/2˝ of the burner.
•
Push in and turn the burner knob to the "High" position. At this point,
•
the burner should light, if it doesn't after 5 seconds, turn the control knob
back to the "Off " position and wait for the gas to clear.
Wait 5 minutes, and then repeat the manual lighting procedure. If after three
•
tries the burner still does not light, review the troubleshooting guide for help.
If the heat output is too low, the flow control feature may have
been activated by a gas leak. If so, turn off the burner valve
and cylinder valve, and perform the "Leak Test". If there aren't
Lighting the Second Burner
Turn the second control knob on the main control panel to the
•
"High" position. The unlit burner will automatically ignite.
Lighting the Side Burner
Use the push-button igniter on the main control panel and the right control knob
on the side burner panel.
Push in and turn the right control knob to the "High" position.
•
Push the igniter button until a loud click is heard, which is the
•
spark being formed. Repeat several times if the burner does not light.
If the burner does not light after several tries, turn the right
•
control knob off and wait 5 minutes for the gas to clear.
Repeat the above instructions. If the side burner still does not light,
•
refer to the troubleshooting section for help or light the burner manually.
Note: The side burner is designed to accept a maximum weight of 20 lb. Do not
overload the side burner.
W A R N I N G
any leaks, re-light the burner.
