P R I O R T O U S I N G
Insert valve outlets into Venturi tubes
approximately 6mm (1/4")
Drawing F
W A R N I N G
Natural Hazards
Insects and Spiders
Drawing G
L I G H T I N G T H E
B A R B E C U E G R I L L
12/22/04 9:03 AM Page 5
Do not use your barbecue until you have carefully read and fully understand all
the information in this manual. Please ensure the following:
Your barbecue is properly assembled.
•
There are no leaks in the system (see "Leak Test").
•
The burner is properly assembled, with the venturi tubes seated over the
•
valve outlets (drawing F) and that there is nothing blocking the venturi
tubes (drawing G).
Ensure that all power cords and/ or gas supply hoses will not touch or be
•
near the surfaces that will get hot.
The barbecue is in a safe location (see installation).
•
Ensure that the valve outlets (igniter electrode) are assembled into the venturi
tubes approximately 6 mm (1/4˝) and that the valve outlets and venturi tubes are
approximately parallel to the bottom of the lower body.
During shipment or storage, it's possible that small insects like spiders could
find their way into the venturi tubes and nest or make webs. This could block
the flow of gas through the venturi tube causing a smoky yellowish flame, or
prevent a burner from lighting. It could even cause the gas to burn outside the
Venturi tube, which could seriously damage your grill. If these occurs, turn off
the gas flow and wait for the barbecue to cool down. When the barbecue has
cooled, remove the burner and clean out the venturi tubes with a brush or pipe
cleaner. Replace the burner and ensure that the venturi tubes are seated over
the Igniter Electrode located on the gas valves. Cleaning the venturi tubes
should be conducted periodically, especially at the start of the season.
Note: Damage resulting from blocked venturi tubes is not covered under
the warranty.
Make sure you have followed all the checks, procedures and instructions
•
indicated in the prior sections before attempting to light the barbecue.
Always raise the barbecue lid before lighting the burner.
•
Do not bend directly over the barbecue while lighting in case of back flash.
•
Making sure the main barbecue control knob is off, slowly and carefully open
•
the propane gas cylinder valve. Wait about five seconds before opening the
burner valve and lighting the barbecue grill. This procedure allows the pressure
to stabilize, and prevents the flow control feature from activating. Note: If the
flow control feature does activate, turn off the burner control valve and the
cylinder valve, wait about one minute then turn on the cylinder valve slowly.
Wait 5 seconds and turn on the burner valve and light the barbecue.
Lighting the Main Burner
This model comes equipped with a built-in side burner and dual controls. The
main burner is controlled by the left control knob, which is on the main control
panel. To light the main burner, use the left control knob only. The right control
knob is used to light the side burner.
5
