T R O U B L E S H O O T I N G G U I D E
Problem
Burner will not light
(match or igniter)
Burners not hot enough
Flames smoky yellow
Burner lights with match
but not with igniter
Flame blows out/down
through base
Too much heat/excessive
flare-up
Flames under heat
control console
Regulator humming
Incomplete flame
For product inquires, parts, and warranty and troubleshooting support, please call 1-877-707-5463.
12/22/04 9:03 AM Page 9
Possible Causes
Blocked venturi tubes
•
Cylinder or gas supply valve turned off
•
Venturi tubes not properly sealed over
•
valve igniter electrodes
Burner ports blocked
•
Low or out of propane
•
Flow control device activated
•
Regulator not fully tightened into cylinder
•
Partially blocked venturi tubes
•
Excess cooking salts on burner
•
Air shutter closed (side and rear rotisserie burner only)
•
Loose wire connection
•
Broken electrode ceramic
•
Poor ground
•
Faulty igniter
•
High wind conditions
•
Propane low
•
Excessive fat in meat
•
Grease drain plugged
•
Cooking system not positioned correctly
•
Blocked venturi tubes
•
This is not a defect or a hazard
•
Plugged, rusted or leaking burner
•
Corrective Action
Clean out blockage
•
Open cylinder or gas supply valve
•
Ensure proper venturi tube assembly
•
Clean/replace burner
•
Refill cylinder
•
Follow correct lighting procedure,
•
and perform leak test
Tighten regulator fully (hand tighten) onto cylinder
•
Straighten fuel hose
•
Clean out blockage
•
Clean burner
•
Open air shutter
•
Make sure all connections are tight
•
Ensure collector box, burner and
•
igniter are assembled properly
Replace igniter
•
Relocate barbecue back towards wind
•
Refill cylinder
•
Trim meat, turn down burner controls and/or fuel supply
•
Clean casting base and burner
•
Clean heat plate
•
Position cooking system correctly
•
Immediately shut off gas at source,
•
allow grill to cool and clean out venturi tubes
Temporary condition caused by high outside
•
temperatures and a full propane cylinder
Clean/replace burner
•
9
