Summary of Contents for Kichler Lighting Richland II
- Page 1 By Ted Collmar at 8:44 am, Dec 07, 2009 Richland II ® ™ A Kichler Select ceiling fan Kichler ® Lighting 7711 East Pleasant Valley Road P.O. Box 318010 Cleveland, Ohio 44131-8010 Instruction Manual Customer Service 866.558.5706 8:30 AM to 5:00 PM EST,...
-
Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the 2. -
Page 3: Tools And Materials Required
Richland II 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Ceiling mounting plate... -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL (cUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building Outlet box structure. -
Page 5: Hanging The Fan
Richland II 5. HANGING THE FAN REMEMBER to turn off the power before you begin. CUL Listed electrial box To properly install your ceiling fan, follow the steps below. Ceiling mounting plate Step 1. Secure the ceiling mounting Plate to... -
Page 6: Make The Electric Connections
6. MAKE THE ELECTRIC CONNECTIONS WARNING: To avoid possible electrical shock, be sure you have turned off the power at the main circuit panel. Power lines 220~240V Green ground Follow the steps below to connect the fan to your household wiring. Use the wire connecting nuts suppled with your fan. -
Page 7: Finishing The Installation
Richland II 7. FINISHING THE INSTALLATION Remove the nuts and washers from the ceiling Ceiling mounting plate mounting plate. Washer Place the wires and connections inside the mounting bracket and the ceiling mounting motor assembly plate. Swing the motor assembly up into position... -
Page 8: Attaching The Fan Blades
9. ATTACHING THE FAN BLADES Step 1. Attach a blade to a blade bracket using the screws, metal washers and fiber washers provided. (Fig. 9) Make sure the blade is straight when set on the blade bracket. Tighten each mounting Screws screw and then repeat this procedure for each Washers... -
Page 9: Installing The Switch Housing
Richland II 11. INSTALLING THE SWITCH HOUSING NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. - Page 10 12. OPERATING INSTRUCTIONS The pull chain controls the 3 speeds of your ceiling fan. 1 pull = High, 2 pulls = Medium, 3 pulls = Low and the 4th pull turns the motor off. The Black Slide Switch on the side of the switch housing controls the direction of the blades "Forward and Reverse".
-
Page 11: Troubleshooting
Richland II 13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check that all fuses or circuit breakers are installed or in the ON position. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection.
