SERVICE MANUAL BMG-435WD
VERSION 2.6

Advertisement

loading
Need help?

Need help?

Do you have a question about the BMG-435WD and is the answer not in the manual?

Questions and answers

Related Manuals for Blastrac BMG-435WD

Summary of Contents for Blastrac BMG-435WD

  • Page 1 SERVICE MANUAL BMG-435WD VERSION 2.6...
  • Page 2 Index 1. Spare parts 2. Electric schedules Electric circuit diagram E00587-1 230V / 12.9A / 50Hz Electric circuit diagram E01532 110V / 28.0A / 50Hz Electric circuit diagram E03951 400V / 6.0A...

  • Page 3: Spare Parts

    1. Spare parts Frame complete...
  • Page 4 Item Part number Description Remarks Qty. E01514-2 Steer 999-9156 Pipe clamp (set) BE0191 M6x50 hexagon socket head screw DIN 912 E01499 Connector 230V / 50hz E00587-1 Electro kit 230V / 50Hz E01521 Electro kit 230V / 60Hz E01532 Electro kit 110V / 50Hz E03951 Electro kit 3x400V / 50Hz BE0641...
  • Page 5 Planetary system...
  • Page 6 Item Part number Description Remarks Qty. E01493 Motor 230V / 50Hz E01522 Motor 230V / 60Hz E01525 Motor 3x400V / 50Hz E01518 Motor 110V / 50Hz E01483_1 Upper coupling E01465 Fill-up block E06195 Upper belt BE0123 M8x35 hexagon head cap scr. DIN912 E07028 Tension pulley...
  • Page 7 Drive mechanism – E07029 Item Part number Description Remarks Qty. E03504 M14x100mm Stud bolt E06181 M14x71mm Stud bolt (USA) BE0120 M14 lock nut DIN985 E04450 Pulley E01483_2 Bottom coupling E01477 Bearing BE0124 Retaining ring Ø45 DIN471 BE0125 Retaining ring Ø90 DIN472 E01462 Central bearing house top...
  • Page 8 Centre axle – E07030 Item Part number Description Remarks Qty. BE0076 Retaining ring Ø25 DIN471 BE0108 Key 5x5x20 DIN6885A BE0074 Retaining ring Ø20 DIN471 E01487 V-pulley BE0110 Key 6x6x20 DIN6885A E01463 Centre axle BE0109 Key 8x7x20 DIN6885A E01488 V-pulley E01461 Central bearing house bottom 222-2331-E Bearing...
  • Page 9 Pulley I – E07024 Item Part number Description Remarks Qty. BE0076 Retaining ring Ø25 DIN471 BE0109 Key 8x7x20 DIN6885A E01460 Bearing house top E03245 Bearing E01486 V-pulley E01458 Bearing house bottom E01489 V-ring seal E01468 Pulley axle I E01474 Flex pin...
  • Page 10 Pulley II – E07025 Item Part number Description Remarks Qty. BE0076 Retaining ring Ø25 DIN471 BE0109 Key 8x7x20 DIN6885A E01460 Bearing house top E03245 Bearing E01486 V-pulley E01458 Bearing house bottom E01489 V-ring seal E01469 Pulley axle II E01474 Flex pin...
  • Page 11 Pulley III – E07026 Item Part number Description Remarks Qty. BE0076 Retaining ring Ø25 DIN471 BE0109 Key 8x7x20 DIN6885A E01460 Bearing house top E03245 Bearing E01486 V-pulley E01458 Bearing house bottom E01489 V-ring seal E01470 Pulley axle III E01474 Flex pin...
  • Page 12 Contra pulley - E07027 Item Part number Description Remarks Qty. BE0076 Retaining ring Ø25 DIN471 BE0108 Key 5x5x20 DIN6885A BE0109 Key 8x7x20 DIN6885A 222-2331-E Bearing BE0077 Retaining ring Ø52 DIN472 E01486 V-pulley BE0127 Retaining ring Ø13 DIN471 E06050 Pulley E01464 Contra pulley axle E01459 Bearing house contra pulley...
  • Page 13 Tension pulley – E07028 Item Part number Description Remarks Qty. BE0129 Retaining ring Ø12 DIN471 E06051 Pulley BE0128 Retaining ring Ø28 DIN472 E06203 Bearing E06054 Tension pulley axle E01508 Cover plate tension pulley BE0130 M10x25 Countersunk head scr. DIN7991 E06421 Bush...
  • Page 14 Diamond plate holder (3x) Item Part number Description Remarks Qty. E01476 Flex disc rubber plate E03292 Flex disc rubber E01472 Flex disc E03293 Diamond disc rubber BE0072 Spring cotter BG300212 Adapter plate for wings BG300213 Adapter plate for polish dots BG300207 Adapter plate for granite / marbles E03749...
  • Page 15 Wings Part number Description Remarks Qty. BG707301 Wing red box 9 pieces 18/20 BG707302 Wing red box 9 pieces 30/40 BG707303 Wing red box 9 pieces 60/80 BG707304 Wing red box 9 pieces 120/150 BG707311 Wing green box 9 pieces 18/20 BG707312 Wing green box 9 pieces 30/40 BG707313...
  • Page 16 2. Electric schedules Electric circuit diagram E00587-1 230V / 12.9A / 50Hz...
  • Page 23 Electric circuit diagram E01532 110V / 28.0A / 50Hz...
  • Page 27 Electric circuit diagram E03951 400V / 6.0A...
  • Page 33 Headquarter Blastrac Poland Blastrac Italy Blastrac The Netherlands Golina, Dworcowa 47a S.S. 10 Padana Inferiore, 41 Utrechthaven 12 PL – 63-200 Jarocin IT – 29012 Caorso (PC) NL – 3433 PN Nieuwegein Tel – 0048 627 40 41 50 Tel – 0039 0523 81 42 41 Tel –...
