  • Page 1 User Manual PPC-4151W Intel® Core i processor based microcomputer, with 15.6" color TFT LCD display...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 4: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 5 Battery Information Batteries, battery packs and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. PPC-4151W User Manual...
  • Page 6 PPC-4151W User Manual...

  • Page 7: Table Of Contents

    Environment Specifications............3 1.2.5 Certification Specifications............3 1.2.6 IP ....................3 Dimensions ....................4 Figure 1.1 PPC-4151W dimensions ..........4 Chapter System Installation & Setup ....5 Quick Start Guide..................6 Figure 2.1 Front panel ..............6 Figure 2.2 Side view ..............7 Figure 2.3 Location of I/O interfaces..........
  • Page 8 Software Configuration ....27 Driver Installation Divers ................. 28 BIOS Setup ..................... 28 4.2.1 Enter BIOS.................. 28 4.2.2 Display Brightness Adjustment ........... 29 4.2.3 COM5 Mode Selection (RS422/485) .......... 30 4.2.4 Wake Up by LAN ................ 31 PPC-4151W User Manual viii...

  • Page 9: Chapter 1 General Information

    Chapter General Information This chapter gives background information on the PPC-4151W panel PC. Sections include:  Introduction  Specifications  Dimensions...

  • Page 10: Introduction

    Introduction The PPC-4151W is a new generation Panel PC with a WXGA (1366 x 768) screen. Most importantly, the system is equipped with a high performance Intel Core i CPU with the heat being dissipated by its high efficiency fanless thermal design. This makes HMI a big step forward in consolidating performance and reliability in one sys- tem.

  • Page 11: Power Specifications

    CB, CCC, UL 1.2.6 IP  Front Panel IP Grade IP65 Note 1: PPC-4151W's power test conditions are as follows: Test Software Test Configuration Test System Memory: Transcend DDR3L 1600 SODIMM 8 GB x 1 HDD: Seagate 500G 2.5” Burn-in 7.0 Win7(64bit) IO: COM Port RS232 loopback x4, USB2.0 device x4,...

  • Page 12: Dimensions

    Dimensions Figure 1.1 PPC-4151W dimensions Supports VESA 100 x 100 mm; please use M4 screw, 6 mm depth Note! (maximum).  Use suitable mounting apparatus to avoid risk of injury. PPC-4151W User Manual...

  • Page 13: Chapter 2 System Installation & Setup

    Chapter System Installation & Setup Sections include:  Quick Installation Guide  Installation Procedures  Install Memory  Install HDD  Install Mini SATA  Install Wireless LAN  Install Expansion Card  AT/ATX Function Switch  Grounding Installation  Hook Installation ...

  • Page 14: Quick Start Guide

    When you place the panel PC upright on the desktop, its front panel appears as shown in Figure 2.1. Figure 2.1 Front panel iKey Home Key Power status indicator, off (S5): orange, on (S0): blue PPC-4151W User Manual...

  • Page 15: Figure 2.2 Side View

    Figure 2.2 Side view Quick installation clip Antenna holes (two) Panel Mounting Bracket holes (ten) Side USB 2.0 interface CPU cooler PPC-4151W User Manual...

  • Page 16: Figure 2.3 Location Of I/O Interfaces

    J: 1 x COM RS422/485 K: PCI/PCIE x1 Expansion slot (refer to E: 2 x Giga Ethernet ports Fig 2.4) F: VGA L: Grounding screw (refer to Fig 2.5) Figure 2.4 PCI expansion slot Figure 2.5 Grounding screw PPC-4151W User Manual...

  • Page 17: Installation Procedures

    Connect Keyboard and Mouse Connect the keyboard and mouse to panel PC’s I/O interfaces. 2.2.2.1 Power ON The power button is located in the right bottom side of the panel PC. Note! Power cable and adapter are optional. PPC-4151W User Manual...

  • Page 18: Install Memory Card

    Remove the black and gray thermal grease from the accessary box (as indicated in Figure 2.12). Attach the CPU heatsink after the grease is applied. Figure 2.11 Figure 2.12 Note! CPU cooler pad surface is isolated by anodization treatment to avoid static electricity (CPU contact side excluded). PPC-4151W User Manual...

  • Page 19: Install The Hdd

    Lock the HDD bracket, and take out the HDD cable from the accessory box and connect it to the mainboard. (See Fig 2.16 ~ 2.18) Figure 2.13 Figure 2.14 Figure 2.16 Figure 2.15 Figure 2.17 Figure 2.18 PPC-4151W User Manual...

  • Page 20: Install Mini Sata

    Take down the two plugs in the left and right sides of the rear cover. (See Fig 2.26) Return the rear cover and install the antenna of the wireless LAN card module. (See Fig 2.27) Note! For wireless LAN card module, you can choose Advantech Product: (Part No. PPC-6150-WLANE). PPC-4151W User Manual...

  • Page 21: Figure 2.23

    Figure 2.23 Figure 2.24 Figure 2.26 Figure 2.25 PPC-4151W User Manual...

  • Page 22: Installing The Riser Card

    PCI riser card (PCM-938) is provided in the accessory box for additional use (See Fig 2.30). The installation of the expansion card is shown as Fig 2.31 and Fig 2.32. Note! The maximum dimension of the expansion card is 167.65 mm x 106.7 Figure 2.28 Figure 2.29 PPC-4151W User Manual...

  • Page 23: At/Atx Function Switch

    Figure 2.30 Figure 2.31 Figure 2.32 AT/ATX Function Switch The switch built into the machine, lets you choose between AT/ATX functions without removing the rear cover. Figure 2.33 ATX mode Figure 2.34 AT mode PPC-4151W User Manual...

  • Page 24: Grounding Installation

    Loosen the screws, remove the plastic cover, plug in the grounding cable, and then fix the screws. (See Fig 2.35 ~ Fig 2.38) Figure 2.35 Figure 2.36 Figure 2.37 Figure 2.38 Note! The grounding cable is not provided in the accessory box. PPC-4151W User Manual...

  • Page 25: Hook Installation

    2.10 Hook Installation Follow the figures below: PPC-4151W Hook Installation Hook Put the machine into the carbinet, and prepare the hook. Install the hook into the hole to hold the machine as shown above Screw Secure the machine by fastening the screws Figure 2.39 Hook Installation...

  • Page 26: Solo Quick Installation

    Users can install the panel on a wall without assistance by following the panel wall- mount installation guide below. Loosen the two screws at the bottom, see the figure below. Push the machine into the gap in the wall, and the spring hook will lock the machine into the wall. PPC-4151W User Manual...

  • Page 27: Cradle Installation Description

    6 mm (0.236”). 2.12 Cradle Installation Description Note! For the cradle, you can choose Advantech product (Part No. PPC- 4150W-STANDE). Please refer to the included description for the instal- lation method. PPC-4151W User Manual...
  • Page 28 PPC-4151W User Manual...

  • Page 29: Jumper Configuration

    Chapter Jumper Configuration Sections include:  Jumper & Connectors  Peripheral COM Port & DIO Switch and Pin Definitions...

  • Page 30: Jumper & Connectors

    Figure 3.1 PCM-8209 front view SW1 Panel Resolution Selection Setting Function 1000 for 15.6" LCD 1110 for 21" LCD CN20 COM1/COM2 RI Type Select Description For COM1/COM2 select RI Voltage mode Setting Function (1-3) (2-4) (default) (3-5) (4-6) (7-9) (8-10) PPC-4151W User Manual...
  • Page 31 CN17 clean CMOS Setting Function (1-2) Clear CMOS (2-3) Keep CMOS (default) SW2 ATX/AT Mode Selection Pin Name ATX Power(default) AT Power CN15 GPIO Pin Name GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 PPC-4151W User Manual...

  • Page 32: External Com Port Pin Definition

    COM4 doesn’t support RING function. COM1-4: COM1 / COM2 COM3 / COM4 RING or 5V/12V output RING (Only COM3) Pin 9 is set as RI signal in COM port by default, and could be set as 5V/12V output by Jumper PPC-4151W User Manual...
  • Page 33 (1) 8 data bits + 1 parity bit + 1stop bit (2) 8 data bits + 1 parity bit + 2 stop bits (3) 8 data bits + 2 stop bits PPC-4151W User Manual...
  • Page 34 PPC-4151W User Manual...

  • Page 35: Software Configuration

    Chapter Software Configuration Sections include:  Driver Installation  BIOS Setup Program...

  • Page 36: Driver Installation Divers

    DVD-ROM may not be the latest version, if needed, please find them at: http://www.advantech.com/ BIOS Setup 4.2.1 Enter BIOS Start the computer and press the “Delete” key to enter BIOS. Press “F4” to save and exit after any configuration, or the configuration won't be saved in BIOS. PPC-4151W User Manual...

  • Page 37: Display Brightness Adjustment

    Select “Brightness Manual Control” under “Brightness Control”, and there will be six options: Note! If you want to adjust the brightness through AP in the OS, it will keep AP configuration mainly, and BIOS configuration will not be saved. PPC-4151W User Manual...

  • Page 38: Com5 Mode Selection (Rs422/485)

    4.2.3 COM5 Mode Selection (RS422/485) Select “Super IO Configuration” under “Advanced”. Select “Serial Port 5 Configuration” and then select the operation mode of COM5 by "Serial Port5 Mode". PPC-4151W User Manual...

  • Page 39: Wake Up By Lan

    4.2.4 Wake Up by LAN Select “ACPI Settings” under “Advanced”. Set "Wake On By LAN or RI" as “Enabled”. PPC-4151W User Manual...
  • Page 40 Then save the configuration and exit the OS. Right click “Computer” and click “Manage”, then open “Computer Management”. Click “Network adapters” in “Device Manage”, then right click and select the needed LAN port, then select “Properties” and open “Intel(R) Ethemet”. PPC-4151W User Manual...
  • Page 41 Select “Work On Magic Packet” .“Work On Pattern Match” and “Work On Magic Packet From Power Off State” under “Power Management”. PPC-4151W User Manual...
  • Page 42 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
