Brickcom FB-100A Series Quick Installation Manual page 5
Megapixel day & night fixed box network camera
Hide thumbs
Also See for FB-100A Series:
- User manual (85 pages) ,
- Quick installation manual (23 pages) ,
- User manual (139 pages)
Advertisement
2. Device Description
<Front Panel>
Status LED
Built-in
Microphone
<Rear Panel>
Power Connector (AC24V in)
Power Connector
(DC12V in)
Auto Iris Connector
SD/SDHC
Card Slot
Reset Button
Microphone/Line
In
Light Sensor
WPS LED
(WFB-100A Only)
Ethernet RJ45 10/100 Socket
(Link/Power LED embedded)
Detachable Antenna
(WFB-100A Only)
Extension I/O
Terminal Block
Audio Out
WPS Button
(WFB-100A Only)
