PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS
PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
Contact your building or fire officials about restrictions and installation
WARNING:
Improper installation, adjustment, alteration,
s e r v i c e
o r
m a i n t e n a n c e
injury, property damage, or loss of life.
Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
GCI60-919-570a
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
Greenfire® GCI60
inspection requirements in your area.
c a n
c a u s e
IMPORTANT: SAVE THESE INSTRUCTIONS
TECHNICAL MANUAL
Cast Iron
Pellet Insert
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.
06.29.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the greenfire gci60 and is the answer not in the manual?

Questions and answers

Summary of Contents for HAMPTON BAY greenfire gci60

  • Page 1 Greenfire® GCI60 TECHNICAL MANUAL Cast Iron Pellet Insert PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. Contact your building or fire officials about restrictions and installation inspection requirements in your area.
  • Page 2 Safety Note: If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions, contact local building, fire officials, or authority having jurisdiction about restrictions and installation inspection requirements in your area. The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit.
  • Page 3: Table Of Contents

    Table of Contents Safety Warnings & Recommendations..............4 Specifications......................6 Rating Label & Location:................6 Specifications......................7 Dimensions:....................7 Specifications:....................7 Installation......................8 Deciding Where to Locate your Pellet Appliance:..........8 Removing Pellet Stove From Pallet:..............8 Installing the Insert Frame & Levelling:............9 Oversize Filler Panel (part # GCI60-918):............10 Thermostat Installation:................10 Minimum Fireplace opening:.................11 Clearances to Combustibles:.................11...
  • Page 4: Safety Warnings & Recommendations

    Safety Warnings & Recommendations * This manual is designed for the technician in conjunction with the owner’s manual. * Please read this entire Technical Manual before installing or operating your Hampton Pellet Stove. Failure to follow these instructions may result in property damage, bodily injury or even death.
  • Page 5 Safety Warnings & Recommendations ELECTRICAL: The use of a surge protected power bar is recommended. The unit must be grounded. The grounded electrical cord should be connected to a standard 110-120 volts (4.2 Amps), 60 hertz electrical outlet and also must be accessible. If this power cord should become damaged, a replacement power cord must be purchased from the manufacturer or a qualified Hampton dealer.
  • Page 6: Specifications

    Specifications & l ating abel ocation The rating label is located on the top of the hopper. Hampton GCI60 Cast Pellet Insert Technical Manual...
  • Page 7: Specifications

    16 ⁄ Specifications imenSionS 43 ⁄ 11 ¾ 26 ⁄ 24 ¾ 16 ⁄ 33 ⁄ 22 ⁄ 12 ¾ 40 ⁄ 43 ⁄ 11 ¾ 50.000 33 ⁄ 38.000 22 ⁄ 12 ¾ 40 ⁄ Oversize Filler Panel Dimensions Regular Cast Faceplate Dimensions pecificationS Input rating when using: Wood Pellets/Corn - 55,000BTU (16.1KW•hr) &...
  • Page 8: Installation

    Installation eciding here to ocate your ellet ppliance 1. Unit must be installed in a masonry fireplace. 2. Do not install the stove in a bedroom or room where people sleep in. 3. Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation.
  • Page 9: Installing The Insert Frame & Levelling

    Installation NOTE: Installer must attach the metal “fireplace altered” tag using screws or nails to the fireplace, in a location readily visible should the fireplace insert be removed, if the fireplace has been modified to accomodate the GCI60. & l nStalling the nSert rame...
  • Page 10: Oversize Filler Panel (Part # Gci60-918)

    Installation # gci60-918): verSize iller anel part 1. If installing the Oversize Filler Panel (50”W x 38”H), do so before sliding unit into place. 2. Secure the filler panel to the backside of the cast faceplate using the 10 x #8 - 32 x 3/8” Thread Rolling Screws.
  • Page 11: Minimum Fireplace Opening

    Installation To Start Stove: Sele LABEL / NE RETIREZ PAS CETTE ÉTIQUETTE grades of wood pel learanceS to ombuStibleS of pellets in the burn INSTALLED AS A FIREPLACE INSERT STOVE MODEL (FPI) / A INSTALLE To Operate Stove: COMME UN MODELE SUR PIED DE POELE. MODE: (Requires Minimum clearances to combustible materials./ Les dégagements minimums aux thermostat contacts...
  • Page 12: Vent Termination Requirements

    Installation ermination equirementS IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER. Table 2: Use in conjunction with Figure 6 for allowable exterior vent termination locations. Letter Minimum Clearance Description 24 in (61 cm) Above grass, top of plants, wood, or any other combustible materials. 48 in (122 cm) Beside/below any door or window that may be opened.
  • Page 13: Outside Fresh-Air Connection

    Installation utSide reSh onnection This Heater must have adequate air for proper combustion in the room that it is installed. A Fresh-air intake is strongly recommended for all installations. Failure to install intake air may result in improper combustion as well as the unit smoking during power failures.
  • Page 14: Masonry Fireplace Installation

    Installation Installation aSonry ireplace nStallation non-combustible manufactured Rain Cap hearth pad (min. 24 gauge galvanized Steel Plate or Flashing steel or similar) must cover combustible flooring underneath, as well as 6” (150 Flexible or Rigid 4" mm) in front of the heater and 6” (150 Stainless Steel Liner mm) to the side of the heater.
  • Page 15: Positive Flue Connection Without A Full Reline (Usa Only)

    Installation (uSa o oSitive onnection Without a eline This unit does not require a full reline (in USA only) when installing into a masonry fireplace, however, it is recommended to ensure proper drafting of the appliance. IMPORTANT: Ensure the chimney and firebox are cleaned and free of all debris, including soot and ashes, before proceeding with this installation.
  • Page 16: Built-In Installation

    Installation uilt nStallation Installation without a masonry fireplace - The GCI60 can be installed without an existing masonry fireplace by building an enclosure for the unit to be installed in. This enclosure must be a minimum of 18” deep, 36” wide and 23-1/4” high and made with ½”...
  • Page 17: Horizontal Exhaust Through Wall Installation

    Installation orizontal xhauSt hrough nStallation Vent installation: install vent at clearances specified by the vent manufacturer. A chimney connector shall not pass through an attic or roof space, closet or similar concealed spaces, or a floor, or ceiling. Where passage through a wall or partition of combustible construction is desired, the installation must conform to CAN/CSA-B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment and with all local regulations, including those referring to regional and national.
  • Page 18: Termination Cap

    Installation recommended - t hrough ertical iSe and orizontal ermination nStallation NOTE - This venting configuration is only for use with the Built-In installation. Termination cap 90°elbow Wall framing Vertical section of vent pipe Wall strap Horizontal frame for thimble Clean out tee Wall thimble...
  • Page 19: Outside Vertical Installations

    Installation utSide ertical nStallationS To accomplish an outside vertical pipe installation, follow the “H ” orizontal xHaust HrougH nstallations section and then finish it by performing the following. 1. Install a tee with clean out on the outside of the house. 2.
  • Page 20: Inside Vertical Installations

    Installation nSide ertical nStallationS 1. Install a tee or 90° elbow on the inside of the house. 2. Install PL vent upward from the tee. Make sure that you install support brackets to keep the vent straight and secure. All joints in the exhaust venting system must be fastened with at least three (3) screws.
  • Page 21: Slider/Damper Set-Up

    Installation lider amper This is used to regulate the airflow through the pellet stove. CONVECTION EXHAUST CHANNEL EXHAUST SENSOR & REMOVABLE PLATE SLIDER NOTE: THE SURROUND DAMPER PANEL MOUNT HAS BEEN REMOVED FOR CLARITY Figure 15: Slider/Damper Plate & Rod in Unit. This unit is designed to operate within a negative pressure range of 0.15-0.17 inches of water column (37-42 Pa) (See image on right for location to measure negative pressure test port).
  • Page 22: Troubleshooting

    Troubleshooting DO NOT: ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. Only qualified technicians should deal with possible internal electrical failures. ● Do not remove from the firebox any screws without penetrating oil lubrication. WHAT TO DO IF: 1.
  • Page 23 Troubleshooting • Exhaust Temperature Sensor failure. Bypass sensor located on Exhaust Blower, if stove now operates properly, the unit may require cleaning or a new sensor. Contact your local dealer for service. • Check the agitator to make sure it is turning properly 3.
  • Page 24 Troubleshooting • Blocked exhaust / venting system - Have stove and venting cleaned and inspected. • Check Vacuum levels at the Vacuum Switch, with a Magnahelic Gauge (readings must be above .07” W.C. on low fire). 7. Light # 4 on Heat output bar flashing. •...
  • Page 25 Troubleshooting 12. The agitator does not turn. • Ensure unit has finished start-up. • Ensure agitator is locked into the drive shaft properly and is not jammed. • Check drive chain assembly and gear motor for damage. • Check the agitator motor is functioning properly. Hampton GCI60 Cast Pellet Insert Technical Manual...
  • Page 26: Wiring Diagram

    Wiring Diagram Black Brown 2µF Capacitor Black Exhaust Blue Combustion Temperature Brown Blower Blue Blue Sensor Black White 120V Ground Air Pump White Plug Green Ground Ignitor White Ground Thermostat White Agitator Blue/Yellow Black Motor White Auger Yellow Yellow Motor Purple Brown Blue...
  • Page 27: Parts List

    Parts List Reference # Description Part # OPTION Log Set GC60-930 OPTION Service Rails GCI60-900 OPTION GCI60 O/S Filler Panel GCI60-918 HOPPER SWITCH GC60-016 not shown HIGH LIMIT TEMP SENSOR 200°F (93°C) MANUAL RESET GF55-011 120°F (49°C) CERAMIC EXHAUST TEMP SENSOR GF55-009 ⅝”...
  • Page 28 Parts List Reference # Description Part # 1/4" SPRING PIN GC60-010 AGITATOR BUSHING LEFT SIDE GC60-012 WIRING HARNESS GC60-030 LATCH BOLT & ROLLERS C/W NUT GC60-031 MOTHERBOARD MOUNTING PANEL GCI60-004 BURN POT SCRAPER TOOL GF55-023 DOOR & ASH DOOR GASKET 9/16 FIRM (10') W/JOINING TAPE(2) GC60-019 CAST FRONT MOUNTING BRACKETS (SET OF 2) GCI60-015...
  • Page 29 Parts List Reference # Description Part # GCI60 Cast Front - CHARCOAL GCI60-201 GCI60 Cast Top - CHARCOAL GCI60-211 GCI60 Cast Side Left - CHARCOAL GCI60-221 GCI60 Cast Side Right - CHARCOAL GCI60-231 GCI60 Cast Ash Door - CHARCOAL GCI60-241 GCI60 Cast Surround Left - CHARCOAL GCI60-251 GCI60 Cast Surround Right - CHARCOAL...
  • Page 30: Parts Diagram - Components

    Parts Diagram - Components Hampton GCI60 Cast Pellet Insert Technical Manual...
  • Page 31: Parts Diagram - Steel

    Parts Diagram - Steel Hampton GCI60 Cast Pellet Insert Technical Manual...
  • Page 32: Warranty

    WARRANTY Limited Lifetime Warranty FPI Fireplace Products International Ltd. and Fireplace Products U.S., Inc. (“FPI”) extends the Limited Lifetime Warranty protection to the original purchaser of this appliance commencing the day of purchase for as long as the appliance remains in the original place of installation. For items covered under the Limited Lifetime policy, see table below.
  • Page 33 WARRANTY All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you). All claims must be complete and provide full details as requested by FPI to receive consideration for evaluation.
  • Page 34 WARRANTY Limitations of Liability: The original purchaser’s exclusive remedy, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. In no event will FPI be liable for any incidental or consequential damages caused by defects in this product.
  • Page 35 WARRANTY Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 37 NOTES Hampton GCI60 Cast Pellet Insert Technical Manual...
  • Page 38 NOTES Hampton GCI60 Cast Pellet Insert Technical Manual...
  • Page 40 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Hampton and Greenfire are registered and / or proprietary trademarks of FPI Fireplace Products International Ltd. ©...
