General Operation - RetroSound Model two User Manual

OPERATING YOUR RADIO

General Operation

Power On/Off
Press the left front knob (#1) to turn the unit on.
will appear on the screen.
RETROSOUND
Press and hold the left front knob (#1) to turn the unit off.
will appear on the screen to confirm that it has turned off.
GOODBYE
Volume
Turn the left front knob (#1) to adjust the volume between 0-46.
Mode
Turn the left rear knob (#2) clockwise to select from available
listening sources: , ,
RADIO AUX 1 AUX 2
(The USB source modes will not appear unless a USB device is
plugged in).
The auxiliary and USB inputs are located at the back of the radio
body. The auxiliary inputs may be used to play music from any
portable device with a standard headphone output, such as a MP3
player, iPod or iPhone , portable CD player or portable satellite
® ®
radio receiver. The USB inputs allow you to control iPod
play music from a flash drive. To use these inputs, the cables must
be routed to an accessible area during installation.
Radio Tuning
Turn the right front knob (#8) to tune to the next or previous
AM/FM frequency.
NOTE: When the radio is tuned to a strong stereo FM station, the stereo indicator will
appear on the upper right corner of the LCD screen (two oval circles).
, , , .
USB 1 USB 2 Bluetooth
/iPhone or
® ®
OPERATING YOUR RADIO
Radio Bands
Turn the right rear knob (#9) counter-clockwise to toggle through
the five radio bands (two AM and three FM).
Storing Radio Pre-sets
There are six radio pre-sets for each radio band. For pre-sets one
through five, tune to the desired radio station and then press and
hold the push-button (#3-7) to store into memory. To store pre-set
number six, tune to the station you want to store, then turn and hold
right rear knob clockwise to store.
Selecting Radio Pre-sets
To recall radio pre-sets, press the appropriate pre-set button (#3-7) in
the selected radio band. To recall pre-set six, turn the right rear knob
(#9) clockwise and release it.
Mute
Press the right front knob (#8) to mute or unmute.
16
