Welcome; What's In The Box - RetroSound Model two User Manual

WELCOME

Thank you for purchasing a RetroSound
Two combines classic styling with the advanced features you
expect from a modern car stereo. Model Two consists of two
main parts: the Model Two radio face and the Motor 3 body.
General Features
• The only classic car radio compatible with iPod
• Built-in Bluetooth for hands-free calling and audio streaming
®
• Plays MP3 and WMA files via USB input
• Selectable 32,000 color LCD illumination with user presets
• AM/FM tuner with 30 presets and RDS
• Selectable USA/EU/JAP/AUS/RUS tuner frequencies
• Built-in amplifier (25 watts RMS/45 watts peak x 4 channels)
• 3 EQ presets plus user-controlled bass, mid-range,
treble, fader, and balance adjustment
• InfiniMount shaft/bracket system for maximum installation flexibility
• Available with period-correct knobs and bezel
• Inputs: 2 rear-mounted standard USB ports and 2 rear auxiliary inputs
• Outputs: 6-channel pre-amp outputs (front, rear, subwoofer)
• Separate power antenna and amplifier turn-on lead(s)
• 2 year parts and labor warranty
The information enclosed in this user's manual is to be used as a guide to assist
you with installation and operation of your radio. This guide does not cover
every installation possibility, vehicle, or every aspect of the installation process.
Retro Manufacturing, LLC, RetroSound
responsibility for any installation. This manual may be updated from time to time.
Visit our website for the latest updates: www.retromanufacturing.com.
Model Two radio. Model
®
and iPhone
® ®
, or its subsidiaries, assume no
®
The items shown below are packaged with your Motor 3 box.
Main Wiring Harness Power and Speaker
(plugs into back of radio) Wiring Harnesses
(both plug into Main
Wiring Harness)
Metal Mounting Back Strap Plastic Washer Kit
and Hardware
The items shown below are packaged with your Model Two face box.
Model Two Radio Face Radio Face
Mounting Screws
InfiniMount Shafts Shaft Covers

WHAT'S IN THE BOX

Motor 3 Radio Body Bluetooth Microphone
®
InfiniMount Brackets Bracket Mounting Hardware
Shaft Mounting Hardware
Vintage Radio Dial
Screen Protectors
4
