INSTALLATION GUIDANCE

Connecting the car adapter and installing the unit
Remove the filter
1
cover.
Insert the car adapter's unit
2
connection plug securely into
the unit power input terminal.
Route the cord in one of the ways
3
shown in the diagram, according
to the place of installation, then
attach the fi lter cover.
• Be careful the cord does not get
Insert the cigar plug into the
4
cigar lighter socket.
• Be sure to remove any dirt from the
IG-DC2A.EN.indd 7 IG-DC2A.EN.indd 7
caught in the fi lter cover.
Hook
Insert it from
lower side
cigar lighter socket. Failure to do so
could cause faulty contact or fi re.
Lock
part
1
Attach
Cigar
plug
E-5
Filter
cover
2
Remove
Cord
Use one
of these
routes.
Upper
Bottom
Cigar lighter
socket
