PARTS NAME

MAIN UNIT • CONTROL PANEL/DISPLAY
Operation
Button
(See E-7)
Unit
Replacing
Light
(red)
(See E-10)
Operation Light
* If the Plasmacluster Ion Generating Unit replacement time comes,
Unit Replacing Light lights up.
Plasmacluster Ion
Generating Unit
Power Input
Terminal
Filter Cover
Do not remove
the cushioning
material from the
back of the cover.
Air Intake
(Filter)
IG-DC2A.EN.indd 6 IG-DC2A.EN.indd 6
IG-DC2
*
BACK
Turbo
Button
(See E-7)
Turbo
Light
(purple)
Ion sign
(blue)
(Inside of main unit)
ACCESSORIES
Car Adapter
Unit Connection Plug
Cord
Cigar Plug
(With 5A glass tube fuse)
Connect to the cigar lighter socket
in the vehicle.
E-4
Air Outlet
Main Unit
