PARTS NAME
FRONT
DISPLAY
Unit Replacing
Light
(red)
(See E-6)
High
(blue)
Operation
Low
(blue)
Button
Fan Speed
Indicator
Filter (Air Intake)
BACK
IG-A10EU.Eng.indd 5
IG-A10EU.Eng.indd 5
Use a pointed object, e.g a pen tip, to press
this button after replacing Plasmacluster Ion
Generating Unit.
Do not press it for any other purpose.
(This is to reset the Unit Replacing Light.)
Power Cord
Plug
E-3
Get other manuals https://www.bkmanuals.com
Louvers
(See E-4)
Top Cover Cap
Screws
Air outlet
Top Cover
Plasmacluster Ion
Generating Unit
(See E-6,7)
Filter (Air Intake)
(See E-5)
