Regency Plateau
Decorative Gas Appliance
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-136a
PTO30 Outdoor
®
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open flame.
•If odour continues, keep away from the appliance and im-
mediately call your gas supplier or fire department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire
department.
WARNING:
Do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance.
Owners &
Installation Manual
Models: PTO30-NG1 / PTO30-LP1
www.regency-fire.com
06.29.16
Advertisement
Table of Contents
Related Manuals for Regency PTO30-NG1
Summary of Contents for Regency PTO30-NG1
- Page 1 Owners & Regency Plateau PTO30 Outdoor ® Installation Manual Decorative Gas Appliance Models: PTO30-NG1 / PTO30-LP1 www.regency-fire.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions What to do if you smell gas: are not followed exactly, a fire •Shut off gas to the appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The Plateau PTO30 Outdoor ® ® decorative gas appliance has been designed to provide you with all the warmth and charm of a fire at the flick of a switch.
-
Page 3: Table Of Contents
PTO30 wall switch and battery installation ....15 (included with unit)............15 PTO60 wall switch and battery installation ....16 (included with unit)............16 PTO30/PT060 Drain Installation (Recommended) ..17 NOTE: PTO60 is two PTO30 units assembled end to end. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 4: Copy Of Safety Decal
Commonwealth of Massachusetts. For the State of Massachusetts, flexible connec- tors shall not exceed 36 inches in length. For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 5: Dimensions
PTO30 UNIT DIMENSIONS 37-9/16" (953mm) TOP VIEW 33-1/4" (844mm) 8-1/4" (210mm) 36-7/16" (932mm) SIDE VIEW END VIEW Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 6: Pto60 Unit Dimensions
PTO60 UNIT DIMENSIONS NOTE: PTO60 is two PTO30 units assembled end to end (see PT060 assembly for more details). 66-7/16" (1688mm) TOP VIEW 8-1/4" (210mm) SIDE VIEW END VIEW Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 7: Important Message
OR CLOTHING IGNITION. deterioration THIS APPLIANCE SHALL BE USED ONLY OUTDOORS IN A WELL-VENTI- LATED SPACE AND SHALL NOT BE USED IN A BUILDING, GARAGE OR ANY OTHER ENCLOSED AREA. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 8: Installation Checklist
30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 9: Important Things To Remember
This will create a pressure zone • Only Regency approved media should be used in the firebox (i.e. at the firebox and will prevent the unit from venting stones/glass) •... -
Page 10: Minimum Clearances To Combustibles
Unit Base to Combustible E1: Alcove Width 30" 84"(2134mm) Wall to Wall (Minimum) E2: Alcove Width 60" 100" (2540mm) F: Alcove Depth 60" (1524mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove 10 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 11: Inner Framing Dimensions (Required)
SIDE VIEW END VIEW NOTE: PTO60 - Four (4) ventilation grills are required for all enclosures. This is to alleviate moisture and allow for air to circulate. Minimum recommended size 20" sq (508 mm²) ea. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 12: Finishing
Optional finishing trim is supplied with the PTO30 - place finishing trim on unit between unit and finishing material. Note: If installing a PTO60 the optional trim on the PTO30 cannot be used and should be discarded. An optional trim (part number 377-957) can be pur- chased for the PTO60. 12 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 13: High Elevation
(clockwise) with a 1/8" flat screwdriver. a soap and water solution or gas leak detector. Note: Screw should be snug, but do not over Do not use open flame for leak testing. tighten. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 14: Pto60 Assembly
2. Remove 9 screws in locations shown below to remove burner tray (re- move from both units). 3. Lift burner tray off-burner tube can remain in place. 6. Install units together into framing (refer to framing section). Secure in place with nailing strips. 14 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 15: Pto30 Wall Switch And Battery Installation
4) Route low voltage wire and battery extension wire through the strain relief. 5) Connect low voltage wire to supplied switch, fasten switch to right side of electrical box (polarity not important). Regency Plateau® PTO30-1 Outdoor Gas Fireplace 08/15/11 919-070... -
Page 16: Pto60 Wall Switch And Battery Installation
11) Place switch in OFF position until fi nal installation is complete. Note: Ensure the battery extension wires are approx. 8" in length inside the electrical box. This excess will ensure ease of battery replacement and servicing in the future. 919-070 08/15/11 16 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 17: Pto30/Pt060 Drain Installation (Recommended)
Cut notches into the top of the coupling reducer to prevent water pooling. Threaded Elbow Threaded @ 90° Reducer (PVC) (PVC) View from under- side of unit. Reducer and elbow can be purchased from your local hardware store. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 18: Pto30 Wiring Diagram
The appliance, when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes with theNational Electrical Code, ANSI/NFPA 70, if applicable. PTO60 WIRING DIAGRAM (PTO60 = 2 X PTO30 ASSEMBLED END-TO-END) Battery Holder ON/OFF Switch 18 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 19: Glass Crystal / Basalt Volcanic Stones Installation
The Burner should not be visible when the flame is out. NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 20: Optional Log Set Installation
3) Install log E on the burner as shown below. Orient log E across log D in the same way and in a similar position as shown in Diagram 4. Diagram 4 20 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-009 04/01/11... - Page 21 6) Install log C on the left side of the burner as shown below. Orient log C in the same way and in a similar position as shown in Diagram 7. Diagram 7 Final Install Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-009 04/01/11...
-
Page 22: Optional Glass Surround Installation
Repeat process on other end. Press down firmly from to secure glass surround/windshield in position. Use care not to scratch surfaces. 22 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-037 10/30/14... - Page 23 This is to alleviate moisture and allow for air to circulate underneath this burner. Mini- See Through Framing Kit Video mum recommended size: 20" sq (508 mm²) ea. Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-141a 11/25/13...
- Page 24 Diagram 6 - Outside Part B Part A Diagram 3 3. Attach inside tall vertical supports (Part B) to short vertical supports (Part C) with one (1) screw each. Part B Part C Diagram 4 24 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-141a 11/25/13...
- Page 25 9. Secure all tall vertical supports (Part B) to Top and Bottom Frame (Part A) with three (3) screws each, Diagram 13 & 14 - Part F If installing optional panels or propane tank drawer - continue on to next Diagram 10 section. Regency Plateau® PTO30-1 Outdoor Gas Fireplace 11/25/13 919-141a...
- Page 26 Diagram 3 - Bend tabs at, panels is supported on headers. 4. Install top panel with six (6) screws in locations shown below. Diagram 2 - Top Panel screw locations 26 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-141a 11/25/13...
- Page 27 When using a LP tank - a minimum 1”(25mm) gap must be maintained at all times, between the floor and base of unit. 1” Max. (Refer to owners manual) 919-031 2” Min. Diagram 1 04/04/12 919-141 Regency Plateau® PTO30-1 Outdoor Gas Fireplace...
- Page 28 This is to alleviate moisture and allow for air to circulate. Minimum recommended size 20"sq (508mm²) ea. * Alternative to installing grills would be to raise the 60`burner frame a minimum of 1" (25mm) to allow air circulation from underneath. 28 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace 03/17/14 919-144...
- Page 29 4. Install four (4) outer vertical supports - secure each support with two (2) screws to top frame and two (2) screws to bottom frame. vent vent vent Diagram 3 - Corner supports with top frame vent Diagram 6 - Outside vertical supports Regency Plateau® PTO30-1 Outdoor Gas Fireplace 919-144 03/17/14...
-
Page 30: Operating Instructions
Unit will repeat step 2. SHUTDOWN PROCEDURE 1. Turn ON/OFF switch. 2. If service is to be performed - you must discon- nect power to the unit, by removing the battery pack. 30 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 31: Copy Of Lighting Plate Instructions
THIS INSTRUCTION PLATE c) L'unité répétera l'étape 2. c) Unit will repeat step 2. appliance. 918-892a Jan 19/10: Created draft for approval Feb 16/10: Changed size of decal xcept er than cut clearance. r approval decal Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 32: Maintenance
Failure to do this will result in burn stains on panels which you will be unable to remove. 5. The heater is finished in a heat resistant paint and should only be refinished with heat resistant paint. Regency uses StoveBright Paint - Metallic Black ®... -
Page 33: Valve Assembly Replacement
14. Rotate HI/LO modulating valve all the way to the left for HI position. 9. Remove green EV2 wire connected to the gas valve. 15. Install new valve assembly and reverse steps 11-1. 16. Test gas connections for leaks. Regency Plateau® PTO30-1 Outdoor Gas Fireplace... -
Page 34: Parts
Burner Mount 377-047 Components Cover 377-028 Burner Tray End 377-048 Pilot Shield support 377-030 Offset Bracket 377-054 Drainage Bracket 376-512 Electronic Assembly NOTE: PTO60 is two PTO30 units assembled end to end. 34 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... - Page 35 Regency Plateau® PTO30-1 Outdoor Gas Fireplace...
-
Page 36: Warranty
At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. 36 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace... - Page 37 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Regency Plateau® PTO30-1 Outdoor Gas Fireplace...
- Page 38 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 39 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 41 Regency Plateau® PTO30-1 Outdoor Gas Fireplace...
- Page 42 42 | Regency Plateau® PTO30-1 Outdoor Gas Fireplace...
- Page 44 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Regency Plateau are trademarks of FPI Fireplace Products International Ltd. © Copyright 2016, FPI Fireplace Products International Ltd. All rights reserved.
