Regency Plateau
Outdoor Decorative Gas Appliances
www.regency-fire.com
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier
Tested by:
919-340c
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
®
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open flame.
•If odor continues, keep away from the appliance and im-
mediately call your gas supplier or fire department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire department.
WARNING:
Do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance.
A LP - cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Series
WARNING: FOR OUTDOOR USE ONLY
Owners &
Installation Manual
MODELS: PTO30CFT-2
Regency Plateau® Outdoor Firetable Video
07.23.18
Advertisement
Table of Contents
Related Manuals for Regency PTO30CFT-2
Summary of Contents for Regency PTO30CFT-2
- Page 1 Regency Plateau Series Installation Manual ® Outdoor Decorative Gas Appliances MODELS: PTO30CFT-2 Regency Plateau® Outdoor Firetable Video WARNING: FOR OUTDOOR USE ONLY www.regency-fire.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions What to do if you smell gas: are not followed exactly, a fire •Shut off gas to the appliance.
- Page 2 Do not store a spare LP cylinder under or near a barbecue grill, or other heat sources. NEVER fill an LP cylinder beyond 80% full: a fire causing death or serious injury may occur. ® Regency Plateau Series Outdoor Gas Fireplace...
- Page 3 To the New Owner: Congratulations! You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The ® Plateau Series Outdoor Decorative Gas Appliance has been designed to provide you with all the ® warmth and charm of a fire at the flick of a switch. The Plateau Series Outdoor Decorative Gas ®...
-
Page 4: Table Of Contents
Operating Instructions ..........26 Lighting Procedure ............26 Shutdown Procedure ...........26 First Fire ..............26 Copy of Lighting Plate Instructions ......27 Maintenance Instructions..........28 Thermocouple replacement .........28 Valve assembly replacement ........29 Parts - coffee table unit ..........31 Warranty ..............32 ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 5: Copy Of Safety Decal
Series Outdoor decorative gas appliance. ® We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being ® improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 6: Unit Dimensions - Coffee Table
UNIT DIMENSIONS - COFFEE TABLE NOTE: Optional glass surround shown ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 7: Important Message
16. The 4 levelling legs on this appliance must not connection for the appliance. LATED SPACE AND SHALL NOT BE be removed. These are for safety and must USED IN A BUILDING, GARAGE OR ANY remain on the appliance. OTHER ENCLOSED AREA. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 8: Installation Checklist
At least 30% of the remaining wall area is open and unrestricted 30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 9: Outdoor Appliance Installation Summary
Do not build up a wall of any type in front or to the sides of the appli- enclosure ance, higher than the firebox opening. This will create a pressure zone • Only Regency approved media should be used in the firebox (i.e. at the firebox and will prevent the unit from venting stones/glass) •... -
Page 10: Minimum Clearances To Combustibles
1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 60" (1524mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove 10 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 11: High Elevation
(or as per local codes) for ease of servicing this appliance. IMPORTANT: Always check for gas leaks with a soap and water solution or gas leak detector. Do not use open flame for leak testing. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 12: Gas Connection
Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Stan- dard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339. 2. Provided with a listed overfilling prevention device. 3. Provided with a cylinder connection device (QCC1/OPD). 12 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 13: Conversion From Lp To Ng
7. Remove gas knob by pulling off - then remove end panel by lifting up and off . Diagram 2 3. Locate LP burner orifi ce. Diagram 7 Diagram 3 Diagram 8 Regency Plateau ® Series Outdoor Gas Fireplace 919-342 06/26/17... - Page 14 NOTE: Top bracket to sit over top of lower bracket. 11. Remove LP hose from valve. Attach supplied "MAX. 0.5 PSI" sticker to top bracket. Bracket LP hose Diagram 14 Diagram 10 919-342a 03.06.18 14 | ® Regency Plateau Series Outdoor Gas Fireplace...
- Page 15 19. Check all gas connections (at valve, regulator, and NG outlet) under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 20. Check inlet and outlet pressures. 21. Reinstall panels. Regency Plateau ® Series Outdoor Gas Fireplace 919-342a 03.06.18...
-
Page 16: Lp Hard Line Conversion
Note: Coffee height table requires removal of only 2 screws (no middle screw). Diagram 1 Diagram 4 5. Remove LP hose from valve. Diagram 2 LP hose Diagram 5 16 | ® Regency Plateau Series Outdoor Gas Fireplace 919-345 01/21/14... - Page 17 12. Check all gas connections (at valve, regulator, and LP outlet) under Bracket normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 13. Check inlet and outlet pressures. Diagram 8 14. Reinstall panels. Regency Plateau ® Series Outdoor Gas Fireplace 919-345 01/21/14...
-
Page 18: Lp Tank Installation
The burner must be inspected annually before being put into service. If dam- age is evident during inspection, the burner must be replaced with FPI part number 378-526. prior to the appliance being put into operation. 18 | ® Regency Plateau Series Outdoor Gas Fireplace... - Page 19 8) To remove - reverse steps 7-5. 3. Reinstall end panels and gas knob. 4. Repeat Step 1 and 2 on other side. 5. Place Table Top on Unit. Final Install Regency Plateau ® Series Outdoor Gas Fireplace 919-112b 01/23/13...
-
Page 20: Glass Crystal / Basalt Volcanic Stones Installation
NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. 20 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 21: Optional Volcanic Stone Installation
Volcanic Stones Ivory /Tan + Glass Crystals For the PTO30, PTO60 For the HZO42 & HZO42AUS & Plateau Series only only Volcanic Stones Slate /Grey + Glass Crystals For the HZO42 & HZO42AUS only Regency Plateau ® Series Outdoor Gas Fireplace 919-050 06/27/11... -
Page 22: Optional Log Set Installation
3) Install log E on the burner as shown below. Orient log E across log D in the same way and in a similar position as shown in Diagram 4. Diagram 4 919-009 04/01/11 22 | ® Regency Plateau Series Outdoor Gas Fireplace... - Page 23 6) Install log C on the left side of the burner as shown below. Orient log C in the same way and in a similar position as shown in Diagram 7. Diagram 7 Final Install Regency Plateau ® Series Outdoor Gas Fireplace...
-
Page 24: Optional Glass Surround Installation
Repeat process on other end. Press down fi rmly from to secure glass surround/windshield in position. Use care not to scratch surfaces. 24 | ® 919-037 Regency Plateau Series Outdoor Gas Fireplace 10/30/14... -
Page 25: Plateau ® Table Cover Installations
1. Place the weather cover over the entire table - when not in use. CAUTION: Never start the unit with the cover on. Let the unit cool before installing the cover. Turn off gas supply to unit before installing cover. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 26: Operating Instructions
« OFF » position. b) Wait 5 minutes - allow unit to cool. c) Clear any obstructions around the thermocouple. d) Repeat steps 3-6. DO NOT place hand over burner when lighting. 26 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 27: Copy Of Lighting Plate Instructions
1. Shut off gas supply to appliance. 2. Laisser l'appareil refroidir à la température ambiante. 2. Allow unit to cool to room temperature 3. Reinstall cover. 3. Remettre le couvercle. DO NOT REMOVE THIS INSTRUCTION PLATE 919-329 Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 28: Maintenance Instructions
Maneuver thermocouple up out of slot, then push down into the unit. 7/16" Diagram 4 - correct thermocouple position Thermocouple Diagram 4 Diagram 2 Correct thermocouple placement Remove front nut 5. Reverse Steps 3 - 1 to reassemble unit. 28 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 29: Valve Assembly Replacement
6. Replace gasket if required. Diagram 2 7. Replace with new valve assembly. 3. Remove gas knob by pulling off. 8. Install gas knob removed in Step 3. 9. Reverse step 2-1 to reinstall. Diagram 3 Regency Plateau ® Series Outdoor Gas Fireplace... - Page 30 Side Panels - Coffee Only 911-089 Propane regulator Hose/Tank 377-926 Table Top - Coffee only (Sunset Bronze) 377-927 Table Top - Coffee only (Stainless) 376-085-TCP Leaf Cover 911-152 Gas Knob Not Shown 919-340 Manual 30 | ® Regency Plateau Series Outdoor Gas Fireplace...
-
Page 31: Parts - Coffee Table Unit
COFFEE TABLE UNIT Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 32: Warranty
All claims must be complete and provide full details as requested by FPI to receive consideration for evaluation. Incomplete claims may be rejected. Revision Date: December 2016 Regency Outdoor Products Warranty 32 | ® Regency Plateau... - Page 33 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: December 2016 Regency Outdoor Products Warranty Regency Plateau ® Series Outdoor Gas Fireplace...
- Page 34 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 35 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 37 Regency Plateau ® Series Outdoor Gas Fireplace...
- Page 38 38 | ® Regency Plateau Series Outdoor Gas Fireplace...
- Page 40 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Printed in Canada Regency, Regency Plateau® are registered trademarks of FPI Fireplace Products International Ltd. © Copyright 2018, FPI Fireplace Products International Ltd. All rights reserved.
