Regency PTO28 Burner Only
Outdoor Decorative Gas Appliance
WARNING: FOR OUTDOOR USE ONLY
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualifi ed installer,
service agency or the gas supplier
Tested by:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-264
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open fl ame.
•If odor continues, keep away from the appliance and im-
mediately call your gas supplier or fi re department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fi re
department.
WARNING:
Do not store or use gasoline or other fl ammable vapours
and liquids in the vicinity of this or any other appliance.
A LP - cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODELS: PTO28 - NG
PTO28 - LP
www.regency-fi re.com
www.regency-fi re.com
08/14/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTO28 - NG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Regency PTO28 - NG

  • Page 1 Owners & Regency PTO28 Burner Only Installation Manual Outdoor Decorative Gas Appliance MODELS: PTO28 - NG PTO28 - LP WARNING: FOR OUTDOOR USE ONLY www.regency-fi re.com www.regency-fi re.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions...
  • Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The PTO28 Burner Only Outdoor Decorative Gas Appliance has been designed to provide you with all the warmth and charm of a fi re at the fl ick of a switch. The PTO28 Burner Only Outdoor Decorative Gas Appliance has been approved by Warnock Hersey/Intertek for both safety and effi...
  • Page 3: Table Of Contents

    Operating Instructions ..........23 Lighting Procedure ............23 Shutdown Procedure ...........23 First Fire ..............23 Copy of Lighting Plate Instructions ......24 Maintenance Instructions..........25 Thermocouple replacement .........25 Switch replacement .............26 Valve assembly replacement ........27 Main assembly.............28 Limited Warranty: ............31 Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 4: Safety Label

    Commonwealth of Massachusetts. For the State of Massachusetts, fl exible connec- tors shall not exceed 36 inches in length. For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 5: Unit Dimensions - Pto28 Burner Only

    DIMENSIONS UNIT DIMENSIONS - PTO28 BURNER ONLY 15-15/16" Measured to (404mm) optional trim 17-15/16" (456mm) 2-1/2" 2-1/2" (64mm) (64mm) 14-7/8" (378mm) 3-9/16" 4-3/16" (89mm) (106mm) Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 6: Important Message

    LATED SPACE AND SHALL NOT BE connection for the appliance. USED IN A BUILDING, GARAGE OR ANY OTHER ENCLOSED AREA. 4. Inspect the burner before each use of the appliance for blockage and any signs of deterioration. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 7: Installation Checklist

    At least 30% of the remaining wall area is open and unrestricted 30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 8: Outdoor Appliance Installation Summary

    fi rebox opening. This will create a pressure zone • Only Regency approved media should be used in the fi rebox (i.e. at the fi rebox and will prevent the unit from venting stones/glass) •...
  • Page 9: Minimum Clearances To Combustibles

    Table Top to Ceiling D: Floor 3-5/8"(92mm) Unit Base to Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 72" (1829mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 10: Inner Framing Dimensions (Required)

    Min. 2" (51mm) wide Non combustible 4-1/8" 7-3/4"(197mm) (105mm) -based on 3/4" finishing material 9-3/4" (248mm) -based on 2-3/8" finishing material Steel studs Steel studs Min. 3-5/8"(92mm) to end of drain holes FRONT VIEW SIDE VIEW Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 11: Finishing

    Nailing strip Burner Opening Size 15-1/16" x 15-1/16 " OPTIONAL FINISHING TRIM Optional fi nishing trim is supplied with the PTO28 - place fi nishing trim on unit between unit and fi nishing material. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 12: High Elevation

    Do not use open fl ame for leak testing. tighten. NOTE: This is a low pressure system. Pressure in excess of 14" will require a pressure regulator to reduce gas fl ow to appliance. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 13: Conversion From Ng To Lp

    4. Remove NG orifi ce #31 and discard—replace with LP orifi ce #50. Diagram 1 2. Remove outer tray by removing 8 screws in locations shown below in Diagram 2. Diagram 4 5. Adjust aeration setting to 1/2" open for LP. Diagram 2 Diagram 5 Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 14 NOTE: If soap bubbles, this would indicate a gas leak. Diagram 10 16. Check inlet and outlet pressures. 9. Remove two (2) screws on the interior of the switch box to release the regulator. Diagram 11 Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 15: Conversion From Ng To Lp - For Use With Lp Tank

    4. Remove NG orifi ce #31 and discard—replace with LP orifi ce #50. Diagram 1 2. Remove outer tray by removing 8 screws in locations shown below in Diagram 2. Diagram 4 5. Adjust aeration setting to 1/2" open for LP. Diagram 2 Diagram 5 Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 16 16. Check all gas connections (at valve, and LP tank) under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 17. Check inlet and outlet pressures. Diagram 11 Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 17: Switch Box Installation

    This can be adjusted from ½ inch to a maximum of 1-½" depending on the fi nished material being used 1/4" increments Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 18: Installation Of Lp Tank

    NOTE: If soap bubbles, this would indicate a gas leak. and tighten butterfl y bolt. Average LP Tank Burn Times High 20lb Tank 13 Hrs NOTE: Inspect hose before each use of appliance. Butterfl y Bolt Diagram 2 Tank Holder Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 19 Maximum of 1" (25.4mm) from base of tank to bottom of opening 30-3/16" 21-7/8" Cylinder Size Opening Size 'A' 5" Max. 10lb (4.5kg) 10in² (25.4cm²) 20lb (9.1kg) 20in² (130cm²) 1" Max. 20-3/8" Min. 2" Min. 20-3/8" Min. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 20: Glass Crystal / Basalt Volcanic Stones Installation

    NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 21: Log Set Installation

    5. Install Log D over Log B and Log A as shown below. 1. Install glass crystals on burner (see instructions in manual). 2. Install Log A on burner in the position shown below. 3. Install Log B in position shown below. Final Install Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 22: Optional Glass Surround Installation

    Repeat process on other end. Press down fi rmly from to secure glass surround in position. Use care not to scratch surfaces. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 23: Operating Instructions

    7. After 30 seconds - release gas control button. If after 30 seconds appliance does not stay lit: a) Turn ON/OFF switch to OFF. b) Wait 5 minutes. c) Repeat steps 3-7. DO NOT place hand over burner when lighting. Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 24: Copy Of Lighting Plate Instructions

    Shut off gas supply to appliance. 3. Laisser l'appareil refroidir à la température ambiante. Allow unit to cool to room temperature Remettre le couvercle. Reinstall cover. DO NOT REMOVE THIS INSTRUCTION PLATE 919-224b Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 25: Maintenance Instructions

    Maneuver thermocouple up out of slot, then push down into the unit. Diagram 3 4. Replace thermocouple - apply silicone to seal where thermocouple comes through the burner tray. 5. Reverse steps 2-1 to reassemble unit. Thermocouple Remove nut Diagram 2 Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 26: Switch Replacement

    4. Push switch outwards. Diagram 1- remove 2 screws 5. Replace with new switch. 2. Pull out plate with switch, disconnect wires to switch. 6. Reverse steps. Diagram 2 - disconnect switch wires Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 27: Valve Assembly Replacement

    5. Remove valve assembly, replace with new valve assembly. 6. Reverse steps 4-1. Diagram 2 3. Remove two interior screws in locations shown below to release valve. Diagram 3 - remove 2 interior screws Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 28: Parts List

    Thermocouple nut 911-143 Switch Cover 940-413/P Replacement Glass (ea) 948-053 Corner Connectors (ea) 904-690 Orifi ce #31 - NG 904-641 Orifi ce #50 - LP 910-246 2 way switch 919-264 Manual Not shown Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 29 NOTES Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 30 NOTES Regency PTO28 Burner Only Outdoor Gas Fireplace...
  • Page 31: Limited Warranty

    Fireplace Products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly ® before it leaves our facility. FPI Fireplace Products International Ltd. is pleased to extend this limited warranty to the original purchaser of a Regency Product. This warranty is not transferable.
  • Page 32 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Regency Plateau are registered trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2013, FPI Fireplace Products International Ltd. All rights reserved.
