Regency Plateau
Outdoor Decorative Gas Appliances
www.regency-fire.com
WARNING:
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
WARNING: For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING:
Do not store or use gasoline, or other flammable vapors and liquids, in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appli-
ance.
Tested by:
920-281a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Series
®
DANGER - FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odour continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in fire or
explosion, which could cause property damage, personal
injury, or death.
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
Owners &
Installation Manual
MODELS: PTO30CFT-11
Regency Plateau® Outdoor Firetable Video
10.19.21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Plateau Series
Summary of Contents for Regency Plateau Series
- Page 1 Series Installation Manual ® Outdoor Decorative Gas Appliances MODELS: PTO30CFT-11 www.regency-fire.com Regency Plateau® Outdoor Firetable Video WARNING: DANGER - FIRE OR EXPLOSION HAZARD If the information in these instructions If you smell gas: are not followed exactly, a fire or •...
- Page 2 Do not store a spare LP cylinder under or near a barbecue grill, or other heat sources. NEVER fill an LP cylinder beyond 80% full: a fire causing death or serious injury may occur. ® Regency Plateau Series Outdoor Gas Fireplace...
- Page 3 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The Plateau Series Outdoor ® Decorative Gas Appliance has been designed to provide you with all the warmth and charm of a fire at the flick of ®...
-
Page 4: Table Of Contents
LP Hard Line Conversion..........18 LP Tank Installation ............20 Table Top Installation ...........21 Glass Crystal / Basalt Volcanic Stones Installation ..22 Optional Log Set Installation ........23 Optional Glass Surround Installation ......25 Plateau Table Cover Installations .........26 ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 5: Copy Of Safety Decal
Series Outdoor decorative gas appliance. ® We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being ® improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 6: Dimensions
UNIT DIMENSIONS - COFFEE TABLE NOTE: Optional glass surround shown ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 7: Gas Installation Checklist
This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. - Page 8 REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed?
-
Page 9: Important Message
ONLY OUTDOORS IN A WELL-VENTI- remain on the appliance. Ensure appliance is connection for the appliance. LATED SPACE AND SHALL NOT BE level prior to use. USED IN A BUILDING, GARAGE OR ANY OTHER ENCLOSED AREA. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 10: Installation Checklist
At least 30% of the remaining wall area is open and unrestricted 30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE 10 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 11: Important Information For Outdoor Fireplace Installations
Do not build up a wall of any type in front or to the sides of the appli- enclosure ance, higher than the firebox opening. This will create a pressure zone • Only Regency approved media should be used in the firebox (i.e. at the firebox and will prevent the unit from venting stones/glass) •... -
Page 12: Minimum Clearances To Combustibles
1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 60" (1524mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove 12 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 13: System Data
(or as per local codes) for ease of servicing this appliance. IMPORTANT: Always check for gas leaks with a soap and water solution or gas leak detector. Do not use open flame for leak testing. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 14: Gas Connection
Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Stan- dard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339. 2. Provided with a listed overfilling prevention device. 3. Provided with a cylinder connection device (QCC1/OPD). 14 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 15: Conversion From Lp To Ng
7. Remove gas knob by pulling off - then remove end panel by lifting up and off . Diagram 2 3. Locate LP burner orifi ce. Diagram 7 Diagram 3 Diagram 8 Regency Plateau ® Series Outdoor Gas Fireplace 919-342 06/26/17... - Page 16 NOTE: Top bracket to sit over top of lower bracket. 11. Remove LP hose from valve. Attach supplied "MAX. 0.5 PSI" sticker to top bracket. Bracket LP hose Diagram 14 Diagram 10 919-342a 03.06.18 16 | ® Regency Plateau Series Outdoor Gas Fireplace...
- Page 17 19. Check all gas connections (at valve, regulator, and NG outlet) under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 20. Check inlet and outlet pressures. 21. Reinstall panels. Regency Plateau ® Series Outdoor Gas Fireplace 919-342a 03.06.18...
-
Page 18: Lp Hard Line Conversion
4. Remove 3 screws in locations shown below to remove side panel. Note: Coffee height table requires removal of only 2 screws (no middle screw). Diagram 1 Diagram 4 5. Remove LP hose from valve. Diagram 2 LP hose Diagram 5 18 | ® Regency Plateau Series Outdoor Gas Fireplace... - Page 19 12. Check all gas connections (at valve, regulator, and LP outlet) under Bracket normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 13. Check inlet and outlet pressures. Diagram 8 14. Reinstall panels. Regency Plateau ® Series Outdoor Gas Fireplace 919-345 01/21/14...
-
Page 20: Lp Tank Installation
The burner must be inspected annually before being put into service. If damage is evident during inspection, the burner must be replaced with FPI part number 378-526 prior to the appliance being put into operation. 20 | ® Regency Plateau Series Outdoor Gas Fireplace... - Page 21 PLATEAU SERIES installation TABLE TOP INSTALLATION TABLE TOP INSTALLATION - BUILT-IN UNIT & COFFEE TABLE UNIT Before installation,stainless steel must be handled and cleaned as per instructions noted below: Stainless Steel Table Top • Stainless table top must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time.
-
Page 22: Glass Crystal / Basalt Volcanic Stones Installation
BURNER PACKAGES Unit Glass Crystals Only *Glass Crystals + Volcanic stones¹ Plateau Series 10 lbs 5lb glass + 1 box stones- recommended NOTE: * Glass Crystals are available in 1lb and 5lb bags. ¹ Glass Crystals to be installed on the burner prior to installing stones. -
Page 23: Optional Log Set Installation
Diagram 3 3) Install Log E on the burner as shown below. Orient Log E across Log D in the same way and in a similar position as shown in Diagram 4. Diagram 4 Regency Plateau ® Series Outdoor Gas Fireplace... - Page 24 WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this ap- pliance may result in property damage or personal injury. 919-009a 10/19/21 24 | ® Regency Plateau Series Outdoor Gas Fireplace...
-
Page 25: Optional Glass Surround Installation
Repeat process on other end. Press down firmly from to secure glass sur- round/windshield in position. Use care not to scratch surfaces. 919-037b 02/24/21 Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 26: Plateau Table Cover Installations
CAUTION: Never start the unit with the cover on. Let the unit cool before installing the cover. Turn off gas supply to unit before installing cover. 26 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 27: Operating Instructions
« OFF » position. b) Wait 5 minutes - allow unit to cool. c) Clear any obstructions around the thermocouple. d) Repeat steps 3-6. DO NOT place hand over burner when lighting. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 28: Copy Of Lighting Plate Instructions
1. Shut off gas supply to appliance. 2. Laisser l'appareil refroidir à la température ambiante. 2. Allow unit to cool to room temperature 3. Reinstall cover. 3. Remettre le couvercle. DO NOT REMOVE THIS INSTRUCTION PLATE 919-329 28 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 29: Maintenance Instructions
Maneuver thermocouple up out of slot, then push down into the unit. 7/16" Diagram 4 - correct thermocouple position Thermocouple Diagram 4 Diagram 2 Correct thermocouple placement Remove front nut 5. Reverse Steps 3 - 1 to reassemble unit. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 30: Valve Assembly Replacement
Diagram 2 7. Replace with new valve assembly. 3. Remove gas knob by pulling off. 8. Install gas knob removed in Step 3. 9. Reverse step 2-1 to reinstall. Diagram 3 30 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 31: Gas Maintenance
• Batteries (remote handheld, remote receiver, volt models) • Flame electrode DC sparker, change as needed) • Burner orifice • Burner media (change as needed) • Thermocouple (millivolt models) • Air shutter setting • Thermopile (millivolt models) • Wiring Gas Leak Tests • Check main gas line connection to valve • Check shut off valve connections • Check connection at gas valve outlet • Check connection at main burner orifice • Check pilot fuel line at valve and at pilot assembly 920-324 09.14.20 Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 32: Parts
Side Panels 376-085-TCP Leaf Cover Sunset Bronze 376-028 Leaf Cover Stainless Steel 911-152 Gas Knob 377-006 Mounting Bracket Table Top (each) 948-223 Regency Logo Plate Not Shown 920-281 Manual Optional Accessories Part # Description 377-926 Table Top Sunset Bronze 377-927... -
Page 33: Coffee Table Unit
COFFEE TABLE UNIT Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 34: Warranty
All claims must be complete and provide full details as requested by FPI to receive consideration for evaluation. Incomplete claims may be rejected. Revision Date: February 2019 Regency Outdoor Products Warranty 34 | ® Regency Plateau... - Page 35 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Regency Plateau ® Series Outdoor Gas Fireplace Revision Date: February 2019 Regency Outdoor Products Warranty...
- Page 36 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 37 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 40 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Printed in Canada Regency, Regency Plateau® are registered trademarks of FPI Fireplace Products International Ltd. © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
