Regency Plateau
Outdoor Decorative Gas Appliances
www.regency-fi re.com
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualifi ed installer,
service agency or the gas supplier
Tested by:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-108a
®
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open fl ame.
•If odor continues, keep away from the appliance and im-
mediately call your gas supplier or fi re department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fi re
department.
WARNING:
Do not store or use gasoline or other fl ammable vapours
and liquids in the vicinity of this or any other appliance.
A LP - cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Series
WARNING: FOR OUTDOOR USE ONLY
Owners &
Installation Manual
MODELS: PTO30CFT-1
PTO30IST-1
PTO30CKT-1
Regency Plateau® Outdoor Firetables Video
06/25/13
Advertisement
Table of Contents
Related Manuals for Regency Plateau PTO30CFT-1
Summary of Contents for Regency Plateau PTO30CFT-1
- Page 1 Installation Manual ® MODELS: PTO30CFT-1 Outdoor Decorative Gas Appliances PTO30IST-1 PTO30CKT-1 Regency Plateau® Outdoor Firetables Video WARNING: FOR OUTDOOR USE ONLY www.regency-fi re.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions What to do if you smell gas: are not followed exactly, a fire •Shut off gas to the appliance.
- Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The Plateau® Series Outdoor Decorative Gas Appliance has been designed to provide you with all the warmth and charm of a fi re at the fl ick of a switch. The Plateau Series Outdoor Decorative ®...
-
Page 3: Table Of Contents
Glass Crystal / Basalt volcanic stones installation ..23 Optional volcanic stone Installation ......24 Optional Log Set Installation........25 Optional glass surround Installation ......27 Riser Installation ............28 (to convert Island into cocktail table) ......28 Plateau® table cover Installations .......30 Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 4: Safety Label
Regency Series Outdoor decorative gas appliance. We have printed a copy of the contents here for your review. NOTE: Regency ® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Dimensions
38" (965mm) 5-1/16" (129mm) TOP VIEW 5-5/8”(143mm) 38”(965mm) 2-9/16”(64mm) 11LB TANK 11LB TANK FLOOR LEVEL 16-11/16”(423mm) 40-5/8”(1030mm) 2-1/16”(52mm) END VIEW Floor to bottom SIDE VIEW of LP tank NOTE: Optional glass surround shown Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 6: Unit Dimensions - Island Table
(156mm) 28-7/8” (733mm) 20lb tank 1” 20lb tank (25mm) 40-3/8” 20-11/16” Floor level (1031mm) 3-1/8” (525mm) (79mm) Floor to bottom of LP tank NOTE: For optional glass surround dimensions - see previous page. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 7: Unit Dimensions - Cocktail Table
12-3/16" (309mm) BURNER GLASS OUTER EDGE OUTER EDGE 36" 914mm TOP VIEW 16 " 16 " 963mm 325mm 8 " 4 " 1248mm 742mm SIDE VIEW END VIEW NOTE: Optional glass surround shown Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 8: Installation
State of 4) Inspect the burner before each use of the OTHER ENCLOSED AREA. California to cause cancer, birth defects or appliance for blockage and any signs of other reproductive harm. deterioration. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 9: Installation Checklist
30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 10: Important Things To Remember
fi rebox opening. This will create a pressure zone • Only Regency approved media should be used in the fi rebox (i.e. at the fi rebox and will prevent the unit from venting stones/glass) •... -
Page 11: Minimum Clearances To Combustibles
When using supplied leveling legs or optional casters. 1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 60" (1524mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 12: High Elevation
Max. Supply Pressure 14" WC (3.49 kpa) Note: If you have an incorrect fl ame pattern, Min. Supply Pressure 11" WC (2.73 kpa) ® contact your Regency dealer for further instructions. Manifold Pressure 10" WC (2.49 kpa) Manifold Pressure-Low 6.4" WC (1.59 kpa) Incorrect fl... -
Page 13: Wiring Diagram
Important: The AA batteries in the battery pack operate the burner switch. If the batteries become weak they will need to be replaced with quality alka- line batteries. This unit will not operate without AA batteries. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 14: Caster Installation
3. Line up caster with existing nutsert (retrofi t) or corresponding hole ( see above diagrams) on plate. Allen key Nutsert 5. After installation, lock out all 4 casters before assembling unit. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 15: Gas Connection
2) Remove long side panel (left panel if you are facing end with ON/OFF Average LP Tank Burn Times switch) to access the 3/8" fi tting to the gas control. High 20lb Tank 8 Hrs 10 Hrs 11lb Tank 3.5 Hrs 4 Hrs Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 16: Conversion From Ng To Lp
3) Slide the burner to the left, away from the pilot assembly and lift out. 6) Re-install pilot cap. 7) Reinstall burner assembly. 8) Adjust aeration accordingly.- see aeration adjustment section manual for details. Burner orifi ce Pilot Cap Regency Plateau ® Series Outdoor Gas Fireplace... - Page 17 Reverse steps to install LP pressure regulator. HI/LO pressure regulator 12) Attach the label “This unit has been converted to LPG” near or on top of the serial # decal. 13) Replace yellow “NG” label with red “LPG” label. Regency Plateau ® Series Outdoor Gas Fireplace...
-
Page 18: Lp Tank Installation - Pto30Cft Only
To avoid tank pressure regulator freezing - when using an 11LB LP tank, it is recommended the appliance is run on low (turned down 30%). 4) Seat tank on tray and tighten butterfl y bolt to secure tank to tray. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 19: Lp Tank Installation
4) Undo butterfl y bolt to release tank. NOTE: If soap bubbles, this would indicate a gas leak. 5) Refi ll tank and reinstall by reversing steps. Gas connection @ tank Butterfl y bolt Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 20: Switch Connection
2) Slide out battery compartment - located below the DFC panel. Battery compartment 2) Connect 2 wires to the switch - position switch in OFF position. 3) Install 4 - AA batteries and reverse steps. 3) Replace panel. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 21: Table Top Installation - Coffee Table Unit
End Caps 8) To remove - reverse steps 7-5. 3) Replace side panel. 4) Repeat Step 1 and 2 on other side. 5) Place Table Top on Unit. Final Install Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 22: (For Island And Cocktail Units Only)
8) With all tiles installed - install inner frame to fi nish installation. 4) Place the 10 fi ller brackets on the table top as shown - before installing tiles. NOTE: Filler brackets are used to fi ll the gaps between each tile. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 23: Glass Crystal / Basalt Volcanic Stones Installation
The Burner should not be visible when the fl ame is out. NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 24: Optional Volcanic Stone Installation
Volcanic Stones Ivory /Tan + Glass Crystals For the PTO30, PTO60 For the HZO42 & HZO42AUS & Plateau Series only only Volcanic Stones Slate /Grey + Glass Crystals For the HZO42 & HZO42AUS only Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 25: Optional Log Set Installation
Diagram 3 3) Install log E on the burner as shown below. Orient log E across log D in the same way and in a similar position as shown in Diagram 4. Diagram 4 Regency Plateau ® Series Outdoor Gas Fireplace... - Page 26 6) Install log C on the left side of the burner as shown below. Orient log C in the same way and in a similar position as shown in Diagram 7. Diagram 7 Final Install Regency Plateau ® Series Outdoor Gas Fireplace...
-
Page 27: Optional Glass Surround Installation
Repeat process on other end. Press down fi rmly from to secure glass surround in position. Use care not to scratch surfaces. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 28: Riser Installation
On the riser, remove panels by grasping bottom and lift backwards, place 4) Remove the 4 adjustable rubber feet form the bottom of the island unit on a soft clean surface. and transfer to the bottom of the island riser. Knockouts Regency Plateau ® Series Outdoor Gas Fireplace... - Page 29 5) Install 8 screws in locations shown below to secure island frame to riser base. 5) Reinstall LP tank and reconnect or reconnect NG gas line. Reinstall panels, table top and glass surround to complete installation. Regency Plateau ® Series Outdoor Gas Fireplace...
-
Page 30: PlateauĀ® Table Cover Installations
CAUTION: Never start the unit with the cover on. Let the unit cool before installing the cover. Turn off gas supply to unit before installing cover. Leaf slides under the unit Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 31: Operating Instructions
After approximately 2 seconds turn on ON/ OFF switch. c) Unit will repeat step 2. SHUTDOWN PROCEDURE 1) Turn ON/OFF switch. 2) If service is to be performed - you must discon- nect the battery pack. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 32: Copy Of Lighting Plate Instructions
Appuyez sur le bouton ON / OFF Si le service est effectuée, vous devez débrancher l'appareil, du bloc-piles, voir le manuel d'instruction pour plus de détails. DO NOT REMOVE THIS INSTRUCTION PLATE 918-628b Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 33: Maintenance Instructions
This is not covered under the terms of the warranty policy. 8) Verify operation after servicing. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 34: Switch Replacement
1) Remove the end panel (side with switch assembly mounted on it) from unit. 2) Remove 2 wire from the switch. 3) Remove 2 screws from switch cover to release switch. 4) Replace switch and reverse steps. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 35: Valve Assembly Replacement
4) Remove orange EV1 wire connected to the gas valve. 5) Remove green EV2 wire connected to the gas valve. 6) Remove HI/LO extension knob. Hi/Lo Extension ground Flame sensor 7) Remove 10 screws in locations shown below to remove valve tray. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 36: Digital Fi Replace Control Replacement
2) Pull down battery compartment - located below the DFC panel. 3) Remove two screws to swing down DFC box. Battery compartment Battery pack 3) Replace 4 - AA batteries and reverse steps. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 37: Parts
Table top frame 911-012 Ignition Board 377-902 Tile set - Slate 326-930 Log Set 377-903 Tile set - Brown 376-522 Cocktail riser 377-080 Inner frame 377-523 Coffee table top 919-108 Manual Not Shown Regency Plateau ® Series Outdoor Gas Fireplace... - Page 38 NOTES Regency Plateau ® Series Outdoor Gas Fireplace...
-
Page 39: Warranty
Fireplace Products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly ® before it leaves our facility. FPI Fireplace Products International Ltd. is pleased to extend this limited warranty to the original purchaser of a Regency Product. This warranty is not transferable. - Page 40 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Regency Plateau® are registered trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2013, FPI Fireplace Products International Ltd. All rights reserved.
