- Page 2 Installation Manual ® MODELS: PTO30CFT-2 Outdoor Decorative Gas Appliances PTO30IST-2 PTO30CKT-2 Regency Plateau® Outdoor Firetables Video WARNING: FOR OUTDOOR USE ONLY www.regency-fire.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions What to do if you smell gas: are not followed exactly, a fire •Shut off gas to the appliance.
- Page 3 To the New Owner: Congratulations! You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The ® Plateau Series Outdoor Decorative Gas Appliance has been designed to provide you with all the ® warmth and charm of a fire at the flick of a switch. The Plateau Series Outdoor Decorative Gas ®...
-
Page 4: Table Of Contents
Shutdown Procedure ...........31 First Fire ..............31 Copy of Lighting Plate Instructions ......32 Maintenance Instructions..........33 Thermocouple replacement .........33 Valve assembly replacement ........34 Parts ................35 Island and cocktail units ..........36 Coffee table unit ............37 Limited Warranty: ............39 Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 5: Copy Of Safety Decal
Series Outdoor decorative gas appliance. ® We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being ® improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 6: Unit Dimensions - Coffee Table
UNIT DIMENSIONS - COFFEE TABLE NOTE: Optional glass surround shown Floor to bottom of LP tank Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 7: Unit Dimensions -Island Table
UNIT DIMENSIONS - ISLAND TABLE NOTE: For optional glass surround dimensions - see previous page. ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 8: Unit Dimensions - Cocktail Table
UNIT DIMENSIONS - COCKTAIL TABLE NOTE: Optional glass surround shown Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 9: Important Message
State of 4. Inspect the burner before each use of the OTHER ENCLOSED AREA. California to cause cancer, birth defects or appliance for blockage and any signs of other reproductive harm. deterioration. ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 10: Installation Checklist
At least 30% of the remaining wall area is open and unrestricted 30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 11: Outdoor Appliance Installation Summary
Do not build up a wall of any type in front or to the sides of the appli- enclosure ance, higher than the firebox opening. This will create a pressure zone • Only Regency approved media should be used in the firebox (i.e. at the firebox and will prevent the unit from venting stones/glass) •... -
Page 12: Minimum Clearances To Combustibles
When using supplied leveling legs or optional casters. 1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 60" (1524mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 13: High Elevation
(or as per local codes) for ease of servicing this appliance. IMPORTANT: Always check for gas leaks with a soap and water solution or gas leak detector. Do not use open flame for leak testing. 12 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 14: Gas Connection
2. Remove end panel by lifting up and off. 5. Reverse steps 1 & 2. Average LP Tank Burn Times High IST/CKT 20lb Tank 8 Hrs 25 Hrs 11lb Tank 3.5 Hrs 11 Hrs Diagram 2 Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 15: Conversion From Lp To Ng
7. Remove gas knob by pulling off - then remove end panel by lifting up and off. Diagram 2 3. Locate LP burner orifi ce. Diagram 7 Diagram 3 Diagram 8 14 | ® Regency Plateau Series Outdoor Gas Fireplace 919-342 01/21/14... - Page 16 Note: Coffee height table requires removal of only 2 screws (no middle screw). Island and Cocktail table units Diagram 9 Location to install 11. Remove LP hose from valve. regulator Access for Hard line (knockout) Diagram 12 LP hose Diagram 10 919-342 01/21/14 Regency Plateau ® Series Outdoor Gas Fireplace...
- Page 17 NOTE: If soap bubbles, this would indicate a gas leak. Diagram 14 20. Check inlet and outlet pressures. 14. Remove connector from end of fl ex line. 21. Reinstall panels. Remove Diagram 15 connector 16 | ® Regency Plateau Series Outdoor Gas Fireplace 919-342 01/21/14...
-
Page 18: Lp Hard Line Conversion
2 scre s no middle scre Diagram 1 Diagram 4 5. Remove LP hose from valve. Diagram 2 LP hose Diagram 5 Regency Plateau ® Series Outdoor Gas Fireplace 919-345 01/21/14... - Page 19 NOTE: If soap bubbles, this would indicate a gas leak. 13. Check inlet and outlet pressures. Diagram 8 14. Reinstall panels. 18 | ® Regency Plateau Series Outdoor Gas Fireplace 919-345 01/21/14...
-
Page 20: Lp Tank Installation - Pto30Cft Only
Note: To turn off gas at LP tank source, lift up panel with handle and tilt forward to access control. Part #: 919-031 Size: 5” W x .77” H (File at 100%) Color: Black font on silver background Warning= black background - silver font Material: Matte Silver DPM Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 21: Lp Tank Installation
WARNING! When using a LP tank - a minimum 1”(25mm) gap must be maintained at all times, between the floor and base of unit. (Refer to owners manual) 919-031 Butterfly bolt 20 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 22: Table Top Installation - Coffee Table Unit
8) To remove - reverse steps 7-5. 3. Reinstall end panels and gas knob. 4. Repeat Step 1 and 2 on other side. 5. Place Table Top on Unit. Final Install Regency Plateau ® Series Outdoor Gas Fireplace 919-112b 01/23/13... -
Page 23: (For Island And Cocktail Units Only)
4) Place the 10 fi ller brackets on the table top as shown - before installing tiles. NOTE: Filler brackets are used to fi ll the gaps between each tile. 22 | ® Regency Plateau Series Outdoor Gas Fireplace 919-113 01/16/12... -
Page 24: Glass Crystal / Basalt Volcanic Stones Installation
The Burner should not be visible when the flame is out. NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 25: Optional Volcanic Stone Installation
Volcanic Stones Ivory /Tan + Glass Crystals For the PTO30, PTO60 For the HZO42 & HZO42AUS & Plateau Series only only Volcanic Stones Slate /Grey + Glass Crystals For the HZO42 & HZO42AUS only 24 | ® Regency Plateau Series Outdoor Gas Fireplace 919-050 06/27/11... -
Page 26: Optional Log Set Installation
Diagram 3 3) Install log E on the burner as shown below. Orient log E across log D in the same way and in a similar position as shown in Diagram 4. Diagram 4 Regency Plateau ® Series Outdoor Gas Fireplace... - Page 27 6) Install log C on the left side of the burner as shown below. Orient log C in the same way and in a similar position as shown in Diagram 7. Diagram 7 Final Install 26 | ® Regency Plateau Series Outdoor Gas Fireplace 919-009 04/01/11...
-
Page 28: Optional Glass Surround Installation
Repeat process on other end. Press down fi rmly from to secure glass surround/windshield in position. Use care not to scratch surfaces. Regency Plateau ® Series Outdoor Gas Fireplace 919-037... -
Page 29: Riser Installation
4) Remove the 4 adjustable rubber feet from the bottom of the island unit on a soft clean surface. and transfer to the bottom of the island riser. Knockouts 28 | ® Regency Plateau Series Outdoor Gas Fireplace 919-043 06/16/11... - Page 30 5) Install 8 screws in locations shown below to secure island frame to riser base. 5) Reinstall LP tank and reconnect or reconnect NG gas line. Reinstall panels, table top and glass surround to complete installation. Regency Plateau ® Series Outdoor Gas Fireplace 919-043...
-
Page 31: Plateau ® Table Cover Installations
1) Place the weather cover over the entire table - when not in use. CAUTION: Never start the unit with the cover on. Let the unit cool before installing the cover. Turn off gas supply to unit before installing cover. 30 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 32: Operating Instructions
« OFF » position. b) Wait 5 minutes - allow unit to cool. c) Clear any obstructions around the thermocouple. d) Repeat steps 3-6. DO NOT place hand over burner when lighting. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 33: Copy Of Lighting Plate Instructions
1. Shut off gas supply to appliance. 2. Laisser l'appareil refroidir à la température ambiante. 2. Allow unit to cool to room temperature 3. Reinstall cover. 3. Remettre le couvercle. DO NOT REMOVE THIS INSTRUCTION PLATE 919-329 32 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 34: Maintenance Instructions
Maneuver thermocouple up out of slot, then push down into the unit. 7/16" Diagram 4 - correct thermocouple position Thermocouple Diagram 4 Diagram 2 Correct thermocouple placement Remove front nut 5. Reverse Steps 3 - 1 to reassemble unit. Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 35: Valve Assembly Replacement
Diagram 2 7. Replace with new valve assembly. 3. Remove gas knob by pulling off. 8. Install gas knob removed in Step 3. 9. Reverse step 2-1 to reinstall. Diagram 3 34 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 36: Parts
Side Panels - Coffee Only 911-089 Propane regulator Hose/Tank 377-926 Table Top - Coffee only (Sunset Bronze) 377-927 Table Top - Coffee only (Stainless) 376-085-TCP Leaf Cover 911-152 Gas Knob Not Shown 919-340 Manual Regency Plateau ® Series Outdoor Gas Fireplace... -
Page 37: Island And Cocktail Units
ISLAND AND COCKTAIL UNITS 36 | ® Regency Plateau Series Outdoor Gas Fireplace... -
Page 38: Coffee Table Unit
COFFEE TABLE UNIT Regency Plateau ® Series Outdoor Gas Fireplace... - Page 39 38 | ® Regency Plateau Series Outdoor Gas Fireplace...
-
Page 40: Limited Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-field service work carried out on your Regency product. FPI will not be liable for results or costs of ®... - Page 41 Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Regency Plateau® are registered trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2014, FPI Fireplace Products International Ltd. All rights reserved. 40 | ®...
