Regency PTO28 City Table
Outdoor Decorative Gas Appliance
WARNING: FOR OUTDOOR USE ONLY
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualifi ed installer,
service agency or the gas supplier
Tested by:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-212b
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open fl ame.
•If odor continues, keep away from the appliance and im-
mediately call your gas supplier or fi re department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fi re
department.
WARNING:
Do not store or use gasoline or other fl ammable vapours
and liquids in the vicinity of this or any other appliance.
A LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODELS: PTO28CIT - NG
PTO28CIT - LP
www.regency-fi re.com
www.regency-fi re.com
06/19/13
Advertisement
Table of Contents
Related Manuals for Regency PTO28CIT - NG
Summary of Contents for Regency PTO28CIT - NG
- Page 1 Owners & Regency PTO28 City Table Installation Manual Outdoor Decorative Gas Appliance MODELS: PTO28CIT - NG PTO28CIT - LP WARNING: FOR OUTDOOR USE ONLY www.regency-fi re.com www.regency-fi re.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions...
- Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The City Table Outdoor Decorative Gas Appliance has been designed to provide you with all the warmth and charm of a fi re at the fl ick of a switch. The City Table Outdoor Decorative Gas Appliance has been approved by Warnock Hersey/Intertek for both safety and effi...
-
Page 3: Table Of Contents
Lighting Procedure ............22 Shutdown Procedure ...........22 First Fire ..............22 Copy of Lighting Plate Instructions ......23 Maintenance Instructions..........24 Thermocouple replacement .........24 Switch replacement .............25 Valve assembly replacement ........26 Main assembly.............27 Burner assembly............28 Limited Warranty: ............31 Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 4: Copy Of Safety Decal
Commonwealth of Massachusetts. For the State of Massachusetts, fl exible connec- tors shall not exceed 36 inches in length. For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 5: Unit Dimensions - City Table
DIMENSIONS UNIT DIMENSIONS - CITY TABLE " 27" 685.83 12 " 323.60 16" 406.27 NOTE: Optional glass surround shown Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 6: Important Message
State of OTHER ENCLOSED AREA. 4. Inspect the burner before each use of the California to cause cancer, birth defects or appliance for blockage and any signs of other reproductive harm. deterioration. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 7: Installation Checklist
At least 30% of the remaining wall area is open and unrestricted 30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 8: Important Things To Remember
fi rebox opening. This will create a pressure zone • Only Regency approved media should be used in the fi rebox (i.e. at the fi rebox and will prevent the unit from venting stones/glass) •... -
Page 9: Minimum Clearances To Combustibles
When using supplied leveling legs. 1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 72" (1829mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 10: High Elevation
Do not use open fl ame for leak testing. tighten. NOTE: This is a low pressure system. Pressure in excess of 14" will require a pressure regulator to reduce gas fl ow to appliance. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 11: Lp Tank Gas Connection
NOTE: If soap bubbles, this would indicate a gas leak. 5. Reverse step 1. Average LP Tank Burn Times High 20lb Tank 13 Hrs NOTE: Inspect hose before each use of appliance. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 12: Lp Hard Line Conversion(For Use In Place Of Lp Tank)
4. Secure regulator in position with top bracket - secure with 2 screws. NOTE: Top bracket to sit over top of lower bracket. Attach supplied "MAX. 0.5 PSI" sticker to top bracket. LP hose Bracket Diagram 2 Diagram 5 Regency PTO28 City Table Outdoor Gas Fireplace... - Page 13 8. Check all gas connections (at valve, regulator, and NG outlet) under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 9. Check inlet and outlet pressures. 10. Reinstall panels. Regency PTO28 City Table Outdoor Gas Fireplace...
-
Page 14: Conversion From Lp To Ng
Inner tray Diagram 1 2. Remove outer tray by removing 8 screws in locations shown below in Diagram 2. Diagram 4 5. Adjust aeration setting to fully closed for NG. Diagram 2 Diagram 5 Regency PTO28 City Table Outdoor Gas Fireplace... - Page 15 7. Remove LP tank and LP hose from valve. Bracket LP hose Diagram 7 Diagram 10 10. Remove connector from end of fl ex line. Remove Diagram 11 Location to install connector Access for regulator Hard line Diagram 8 Regency PTO28 City Table Outdoor Gas Fireplace...
- Page 16 16. Check all gas connections (at valve, regulator, and NG outlet) under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 17. Check inlet and outlet pressures. 18. Reinstall panels. Regency PTO28 City Table Outdoor Gas Fireplace...
-
Page 17: Table Top Installation
This is not a warranty item. 1. Place table top on unit. 2. Secure each corner with the bolt/nutsert. Diagram 2 Secure each corner with a bolt. 3. Reverse steps to remove. Diagram 1 Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 18: Glass Crystal / Basalt Volcanic Stones Installation
NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 19: Log Set Installation
5. Install Log D over Log B and Log A as shown below. 1. Install glass crystals on burner (see instructions in manual). 2. Install Log A on burner in the position shown below. 3. Install Log B in position shown below. Final Install Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 20: Optional Glass Surround Installation
Repeat process on other end. Press down fi rmly from to secure glass surround in position. Use care not to scratch surfaces. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 21: City Table Cover Installation
1. Place the weather cover over the entire table - when not in use. Diagram 1 Diagram 3 CAUTION: Never start the unit with the cover on. Let the unit cool before installing the cover. Turn off gas supply to unit before installing cover. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 22: Operating Instructions
7. After 30 seconds - release gas control button. If after 30 seconds appliance does not stay lit: a) Turn ON/OFF switch to OFF. b) Wait 5 minutes. c) Repeat steps 3-7. DO NOT place hand over burner when lighting. Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 23: Copy Of Lighting Plate Instructions
Shut off gas supply to appliance. 3. Laisser l'appareil refroidir à la température ambiante. Allow unit to cool to room temperature Reinstall cover. Remettre le couvercle. DO NOT REMOVE THIS INSTRUCTION PLATE 919-224b Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 24: Maintenance Instructions
4. Replace thermocouple - apply silicone to seal where thermocouple comes Maneuver thermocouple up out of slot, then push down into the unit. through the burner tray. 5. Reverse steps 2-1 to reassemble unit. Thermocouple Remove nut Diagram 2 Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 25: Switch Replacement
Lift panel up slightly by handle and pull outwards. Place panel on a soft clean surface. Handle Remove this panel Diagram 1 Diagram 3 Disconnect wires. 4. Push switch outwards. 5. Replace with new switch. 6. Reverse steps. Diagram 2 Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 26: Valve Assembly Replacement
Diagram 2. Diagram 2 3. Slide burner away from orifi ce and remove as shown below in Diagram 3. Diagram 5 6. Replace with new valve assembly. 7. Reverse steps 4 -1 Diagram 3 Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 27: Parts List
Side Panel (no slots) 286-025/G City Table Leaf Cover (Grey) 286-037 City Table Leaf Cover (Stainless) 286-938 Seasonal weather cover 948-054 Rubber legs (each) 910-246 2 way switch 919-212 Manual Not shown Supplied by others Regency PTO28 City Table Outdoor Gas Fireplace... -
Page 28: Burner Assembly
286-010 Burner bracket 286-011 Burner bracket 2 286-012 Burner bracket 3 Valve (SIT) 286-017 Valve Bracket (SIT) 286-016 Valve Holder 286-031 Thermocouple mount 911-132 Thermocouple 286-032 Burner Bracket 286-033 Valve Tray Heat Shield Regency PTO28 City Table Outdoor Gas Fireplace... - Page 29 NOTES Regency PTO28 City Table Outdoor Gas Fireplace...
- Page 30 NOTES Regency PTO28 City Table Outdoor Gas Fireplace...
-
Page 31: Limited Warranty
Fireplace Products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly ® before it leaves our facility. FPI Fireplace Products International Ltd. is pleased to extend this limited warranty to the original purchaser of a Regency Product. This warranty is not transferable. - Page 32 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Regency Plateau are registered trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2013, FPI Fireplace Products International Ltd. All rights reserved.
