Specifications - ECS A55F-M2 V.2.0 User Manual

4

Specifications

CPU
Chipset
Memory
*1.Due to the limitation of chipset spec, it supports up to 1866 MHz for
motherboard with a single DIMM per channel.
*2.Please refer to Memory QVL for more information.
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
System BIOS
AP support
*Microsoft .NET Framework 3.5 is required.
• FM1 for AMD A series processors
• Supports CPU up to 100W TDP
• AMD A55 (Hudson D2)
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to
• Supports DDR3 DDR3
• 1 x PCI Express Gen2 x16 slot
• 2 x PCI Express x1 slots
• 1 x PCI slot
• Supported by AMD A55 (Hudson D2)
6 x Serial ATA 3Gb/s Host Controllers
• Realtek ALC662 6-Ch High Definition audio CODEC
• Compliant with HD audio specification
• Realtek 8111E VL Gigabit LAN
• Realtek 8105E VL 10/100 LAN (optional)
• 1 x D-sub (VGA) port
• 1 x HDMI port (DVI port optional)
• 1 x PS/2 keyboard and mouse combo connector
• 8 x USB 2.0 ports
• 1 x RJ45 LAN port
• 1 x Audio port (Line in, microphone in and line out)
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• 6 x Serial ATA 3Gb/s connectors
• 1 x COM header
• 1 x LPT header
• 1 x Front panel audio header
• 1 x Case Open header
• 1 x Speaker header
• 1 x Clear CMOS header
• 1 x SPDIF out header
• AMI BIOS with 32Mb SPI Flash ROM
• Supports Multi-language BIOS Utility
• Supports ECS M.I.B III Utility
• Supports eBLU*/eDLU/eSF*/EZ Charger
Introducing the Motherboard
2
1866* /1600/1333 SDRAM
1
32* GB
