Brief Introduction

Specifications

CPU
•
•
Note: Please go to our website for the latest CPU support list.
Chipset •
Memory
•
•
•
Note: Please go to our website for the latest Memory support list.
Expansion
•
Slots
Storage
•
Audio
•
LAN •
•
Rear Panel I/O
•
•
•
•
•
•
•
Internal I/O
•
Connectors &
•
Headers
•
•
•
•
•
•
•
•
•
•
•
H310CH5-TI2 USER MANUAL
LGA1151 socket for Intel
Supports CPU up to 65W
®
Intel H310 Chipset
Dual channel memory architecture
2 x DDR4 SO-DIMM sockets support up to 32 GB
Supports DDR4 2666/2400 MHz SDRAM
2 x M.2 slots
- 1 x M.2 socket (Key E) type 2230 supports Wifi (PCIe Gen.2) /
BT
- 1 x M.2 socket (Key M) type 2260/2280 supports SSD (SATA/
PCIe Gen.2)
®
Supported by Intel
- 2 x Serial ATA 6Gb/s devices
Realtek ALC662-VD0-GR
- 6 Channel High Definition Audio Codec
- Compliant with HD audio specification
Realtek RTL8111H Gigabit LAN
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
1 x 19V DC_IN port
1 x D-sub (VGA) port
1 x HDMI port
2 x USB 3.0 ports
1 x RJ45 LAN connector
2 x USB 2.0 ports
2 x Audio ports (1 x line-out, 1 x Microphone)
1 x 4-pin CPU_FAN connector
1 x 4-pin SYS_FAN connector
1 x USB 3.0 header supports additional two USB 3.0 ports
1 x 8-pin USB 2.0 header (black) supports card reader and cam-
era or other USB2.0 device
1 x 5-pin USB 2.0 header (yellow) supports touch panel or other
2.0 device
2 x Serial ATA 6Gb/s connectors
1 x Front Panel switch/LED header
1 x Front Panel audio header
1 x Clear CMOS jumper
1 x COM header
1 x Case open header
1 x TPM header
1 x Amplifier Speaker header
1 x SATA power connector
®
Coffee Lake processor
H310 Express Chipset
