Table of Motherboard Components
LABEL
1. CPU Socket
2. SYS_FAN
3. CPU_FAN
4. DDR3_1~2
5. ATX_POWER Standard 24-pin ATX power connector
6. SPI_DEBUG
7. SATA1~6
8. F_PANEL
9. SPDIFO
10. CLR_CMOS
11. F_USB1
12. F_USB2
13. SPK
14. LPT
15. COM
16. CASE
17. PCI
18. PCIE1~2
19. PCIEX16
20. F_AUDIO
21. ATX12V
This concludes Chapter 1. The next chapter explains how to install the motherboard.
COMPONENTS
FM1 for AMD A series processors
System cooling fan connector
CPU cooling fan connector
240-pin DDR3 SDRAM slots
SPI debug header-for factory use only
Serial ATA 3Gb/s connectors
Front panel switch/LED header
SPDIF out header
Clear CMOS jumper
Front panel USB 2.0 header（with EZ Charge function）
Front panel USB 2.0 header
Speaker header
Onboard parallel port header
Onboard serial port header
Case open header
32-bit add-on card slot
PCI Express x1 slots
PCI Express slot for graphics interface
Front panel audio header
4-pin +12V power connector
