Specifications

CPU
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
2
• FM2+ socket for AMD A series APU in the FM2/FM2+ package
• Supports CPU up to 100W TDP
Note: Please go to ECS website for the latest CPU support list.
• AMD A68 Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 Long DIMM sockets support up to 16 GB
• Supports DDR3 2133(FM2+)*/1866(FM2)*
Note: *Due to the limitation of chipset spec, it supports up to
2133/1866 MHz, 1.5V memory with a single DIMM per channel.
Please go to ECS website for the latest Memory support list.
• 1 x PCI Express x16
• 1 x PCI Express x1 Gen2 slot
• 1 x PCI slot
Note: *FM2+ supports PCI Express Gen3, FM2 supports PCI
Express Gen2.
• Supported by AMD A68 (Bolton-D2)
- 4 x Serial ATA 6Gb/s devices
• Realtek ALC662-VD0-GR 6-Ch High Definition audio CODEC
- 6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
• Realtek RTL8111G Giga Lan
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x HDMI port
• 1 x D-Sub port (VGA)
• 2 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, Line out, Mic_in Rear)
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 4 x SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Front panel USB power select jumper
• 1 x Rear USB 2.0/PS2 power select jumper
• 1 x Rear USB 3.0/PS2 power select jumper
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
A68F2P-M2 USER MANUAL
MHz DDR3 SDRAM
Gen3* slot
