Specifications - ECS X79R-AX Manual

4

Specifications

CPU
Chipset
Extra Chips
Memory
Expansion Slots
Storage
USB
Audio
• Accommodates Intel
LGA2011 package
• Supports "Hyper-Threading" technology CPU
• Four PCI Express x16 Gen 3 ports supporting up to 8 GB/
s data transport bandwidth (the second and the forth runs
at x8 mode)
• Intel X79 Express Chipset
• Two ASM1061
Controllers and two eSATA 6Gb/s Host Controllers
• Two Ti Chips, Ti TUSB7340 supports the four USB 3.0
ports at the rear I/O, Ti TUSB7320 supports the Front
USB 3.0 header (two ports)
• Four-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 64 GB
• Supports DDR3 2400(OC)/2133(OC)/1866(OC)/1600/
1333/1066 MHz DDR3 SDRAM
• Supports Intel
memory modules
• 4 x PCI Express x16 Gen 3 slots (the second and the
forth runs at x8 mode)
• 2 x PCI Express x1 slots
• Supported by Intel X79 Express Chipset
- 4 x Serial ATA 3Gb/s Host Controllers
- Support SATA RAID 0, 1, 5 and 10
- 6 x Serial ATA 6Gb/s Host
- The first and the second SATA support SATA RAID 0
and 1
• Supported by ASM1061
- 2 x Serial ATA 6Gb/s ports supporting 2 x SATA
6Gb/s device
- 2 x eSATA 6Gb/s ports supporting external SATA 6Gb/
s devices
*1.If you want to know more about the four gray SAS6G1-2/
3-4 ports near the white SATA ports, please refer to the ECS
website.
*2.Only the X79R-AX has these chips.
• Supported by Intel X79 Express Chipset
- 10 USB 2.0 ports (6 ports at the rear I/O panel and 2 USB
2.0 headers supporting additional 4 ports).
• Realtek ALC892 supports 7.1 channel HD audio
- 7.1+2 channel multi-streaming enables concurrent
gaming/VoIP
- All ADCs supports 44.1k/48k/88.2k/96k/176.4k/195KHz
sample rate
Introducing the Motherboard
®
Sandy Bridge-E processors in the
Chips* integrate two EXSATA 6Gb/s Host
®
Extreme Memory Profile (XMP)
Controllers*
2
Chips*
1
