IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER

SAFETY NOTICE

If this stove is not properly installed, a house
fire may result. For your safety, follow the
installation instructions.
building or fire officials about restrictions
and installation inspection requirements in
your area.
TESTED and LISTED to CAN/ULC S627
AND UL 1482
Meets the Environmental Protection
Agency's May 2015 Particulate Emission
Standards
©PACIFIC ENERGY FIREPLACE
130715-24
PRODUCTS LTD. - 2015
Contact local
NEO16 - NEWCASTLE
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL - NEO 1.6 NEWCASTLE
SERIES - A
SERIAL #
5055.855

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEO 1.6 NEWCASTLE and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific energy NEO 1.6 NEWCASTLE

Summary of Contents for Pacific energy NEO 1.6 NEWCASTLE

  • Page 1: Safety Notice

    TESTED and LISTED to CAN/ULC S627 AND UL 1482 Meets the Environmental Protection Agency's May 2015 Particulate Emission Standards MODEL - NEO 1.6 NEWCASTLE SERIES - A ©PACIFIC ENERGY FIREPLACE 130715-24 NEO16 - NEWCASTLE 5055.855 PRODUCTS LTD. - 2015...

  • Page 2: Table Of Contents

    Label ..........................23 PLEASE SAVE THESE INSTRUCTIONS This manual describes the installation and operation of the Pacific Energy, NEWCASTLE 1.6 Freestanding wood stove. This woodstove meets the 2015 U.S. Environmental Protection Agency's crib wood emission limits for wood woodstoves sold after May 15, 2015. Under specific test conditions this woodstove has been shown to deliver heat at rates ranging from 9,200 to 34,800 Btu/hr.

  • Page 3: Safety

    Chimney fires are easy to detect; they usually involve one or more of the following: -Flames and sparks shooting out of the top of the chimney -A roaring sound -Vibration of the chimney 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 4: Operation

    2. Place crumpled newspaper in the centre of the woodstove Your PACIFIC ENERGY woodstove is designed for many years and criss-cross with several pieces of dry kindling. Add of trouble free operation. Over firing the appliance will shorten a few small pieces of dry wood on top.

  • Page 5: Restarting After Extended Or Overnight Burns

    ING THE WOODSTOVE. EMBERS CAN FALL AND MAY through the chimney. The amount of draft in your chimney IGNITE WOOD BENEATH STOVE. depends on the length of the chimney, local geography, nearby obstructions and other factors. 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 6: Maintenance

    Failure to prevent ash or soot from falling into the baffle tube will cause incorrect operation and will lead to premature burn out of the tube or baffle. 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 7: Maintenance Checks

    - Please contact your dealer if you experience any of the damage listed above. Continuing to operate your stove with bro- ken parts may accelerate damage to other parts and may void your warranty 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 8: Cast Iron Parts

    2) The Top Wings can be removed by lifting and gently rotat- ing back and forth. This will slowly slide the pin from the bushing in the mounting bracket. Fig #2 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
  • Page 9 5) While supporting the side panel, remove the two bolts FIG. #4 BOLTS securing the top of the side panel to the unit. Fig. #4 6) Lift the side panel to disengage the bottom brackets from the slots in the leg bottom. 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
  • Page 10 Remove the screws securing the leg adapter cover to the mounting brackets on the left and right of the leg adapter cover. Fig. #7 11) Reverse all previous steps in order when installing new or replacement pieces. SCREW AND MOUNTING BRACKET 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 11: Ember Protection

    If blockage occurs, flue gases may enter living space. 16" [406mm] Non-combustible floor protector 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 12: Residential Installation

    (3 m.). The installation must meet all local codes. Do not connect this unit to a chimney flue serving another appliance. Minimum system height is 15 feet (4.6 m.) (measured from base of appliance). 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
  • Page 13 Double Wall Connector - Residential 11" 5" 11" 5" 279mm 127mm 279mm 127mm 3" 15" 8" 76mm 381mm 8" 8" 203mm 203mm 203mm 21 1/2" 21 1/2" 549mm 549mm 3" Alcove: Min. Height 7' 76mm Max. Depth 3' 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
  • Page 14 Hooded vent or * 4" diameter air inlet with rodent screen 90 elbow turned down * If the crawl space is well ventilated it is not necessary to extend air inlet to outside 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
  • Page 15 * 4" diameter air inlet with rodent screen Hooded vent or * If the crawl space is well ventilated 90 elbow turned down it is not necessary to extend air inlet to outside 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 16: Mobile Home Installation

    Attach rain cap and check flashing for leaks. your chimney supplier for installation advice. 8. Install connector as per manufacturer's instructions. 9. Attach stove to flooring using two 1/4" x 2" or longer lag screws. 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 17: Optional Blower

    "Man" and set the speed control to desired setting. This will bypass the sensing device and allow full control of the blower. Switching from "Auto" to "Man" or selecting speed may be done anytime. FIG. #14 PIPE SHIELD (CA16.78729) OUTSIDE AIR ADAPTER (OAIR.1A) 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 18: Troubleshooting

    1. Combustion air supply blocked - Check outside air supply for obstruction - Check that room air cover is removed 2. Draft too low - Chimney plugged or restricted, inspect and clean - Chimney oversized or otherwise unsuitable, consult Dealer 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 19: Replacement Parts - Neo 1.6

    15 ..Ash Dump Assembly ........NE16.7857 PORCELIN BLACK: ............BKA PORCELIN MAJOLICA BROWN ........BNA PORCELIN ANTIQUE WHITE ...........AWA METALIC BLACK PAINT..........MBKA All parts may be ordered from your nearest Pacific Energy dealer. http://www.pacificenergy.net for the location of the dealer nearest you. 130715-24 ©PACIFIC ENERGY FIREPLACE...

  • Page 20: Understanding & Operating Your Pacific Energy Stove

    Understanding & Operating Your Pacific Energy Stove The Pacific Energy line of woodstoves is a culmination of OPERATING TIPS years of research and development. Designed to be efficient, clean-burning and user-friendly, this heater will give you years 1. Always use dry, seasoned firewood, up to 16"(406mm) long.

  • Page 21: Firebrick Installation Instructions

    (39 mm x 115 mm x 32 mm) 248.0 3” X 4 1/2” X 1 1/4” (77 mm x 115 mm x 32 mm) 247.0 9” X 4 1/2” X 1 1/4” (230 mm x 115 mm x 32 mm) 5096.99 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.

  • Page 22: Warranty Information

    3 Year Comprehensive Pacific Energy will replace or repair any part found to be defective (parts and labor) for three years from the date of pur- chase. This coverage includes electrical components (blowers, speed controls and thermal switches).

  • Page 23: Label

    Label MUR COTE MUR ADJACENT SIDE WALL ADJACENT WALL COTE SIDE 130715-24 ©PACIFIC ENERGY FIREPLACE PRODUCTS LTD.
  • Page 24 PACIFIC ENERGY FIREPLACE PRODUCTS LTD. 2975 Allenby Rd., Duncan, B.C. V9L 6V8 For technical support, please contact your retailer. Web site: http://www.pacificenergy.net Printed in Canada...
