IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER

SAFETY NOTICE

If this stove is not properly installed, a
house fi re may result. For your safety,
follow the installation instructions. Contact
local building or fire officials about
restrictions and installation inspection
requirements in your area.
TESTED and LISTED to CAN/ULC S627
AND UL 1482
Meets the Environmental Protection
Agency's July 1990 Particulate Emission
Standards
241013-20
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL - NEO 1.6
SERIES - A
NEO16
SERIAL #
5055.700

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEO 1.6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pacific energy NEO 1.6

Summary of Contents for Pacific energy NEO 1.6

  • Page 1: Safety Notice

    TESTED and LISTED to CAN/ULC S627 AND UL 1482 Meets the Environmental Protection Agency's July 1990 Particulate Emission Standards MODEL - NEO 1.6 SERIES - A 241013-20 NEO16 5055.700...

  • Page 2: Table Of Contents

    Optional Blower ......................... 14 Blower Operation ..........................14 Optional Outside Air Adaptor ....................... 14 Troubleshooting ......................... 15 Replacement Parts - NEO 1.6 ......................16 Understanding & Operating Your Pacifi c Energy Stove ................ 17 Label ..............................19 PLEASE SAVE THESE INSTRUCTIONS NOTE: WE STRONGLY RECOMMEND THAT SMOKE DETECTORS BE INSTALLED.

  • Page 3: Safety

    Safety Creosote Formation and Need for In Case of a Chimney Fire Removal 1. Prepare to evacuate to ensure everyone's safety. Have a well understood plan of action for evacuation. Have a When wood is burned slowly, it produces tar and other or- place outside where everyone is to meet.

  • Page 4: Operation

    2. Place crumpled newspaper in the centre of the heater Your PACIFIC ENERGY heater is designed for many years of and criss-cross with several pieces of dry kindling. Add trouble free operation. Over fi ring the appliance will shorten a few small pieces of dry wood on top.

  • Page 5: Restarting After Extended Or Overnight Burns

    Restarting After Extended or Overnight Ash Removal Burns Caution: Ashes are to be removed only when the heater is cold. Whenever ashes get 3 to 4 inches deep in your fi rebox, and 1. Open door and rake hot embers towards the front of the when fi re has burned down and cooled, remove excess heater.

  • Page 6: Maintenance

    Maintenance 1. Burn wood only, dry and well seasoned. The denser or To remove broken glass, remove the door gasket and then heavier the wood when dry, the greater its heat value. This undo the eight screws securing the gasket guides and glass is why hardwoods are generally preferred.

  • Page 7: Maintenance Checks

    Maintenance Checks Check the following parts for damage such as cracks, excessive corrosion, burned out sections and excessive warping: (See website for descriptions and more detail) Some warping of the baffle is normal(up to 1/4” or .65cm). Replace if the baffle has permanent warp- ing greater than this or has signs of cracking or breakage.

  • Page 8: Assembly

    NEO 1.6 Dimensions 20 1/8" 17 7/16" 27 1/8" 6" 36 15/16" 36" NOTE: DIMENSION DOES NOT INCLUDE LEVELLING LEGS Assembly Crate Removal 1) Carefully remove wood top and supports. 2) Remove plastic cover. 3) Using a 7/16" wrench, remove lag bolts that secure stove body to bottom pallet.
  • Page 9 FIG. #2 3) Engage the tabs in the panel into the slots in the panel mounting bracket. Fig. #2 4) Attach the panel to the rear shield. Secure with two screws. Fig. #3 FIG. #3 SCREWS 241013-20 NEO16...

  • Page 10: Floor Protector

    Floor Protector Combustion Air Intake or combustion air can be supplied to the stove in one The stove may be installed on a combustible fl oor provided of two ways. Consult your local building code or CAN/CSA- noncombustible ember protection is used. B365, Installation Code for Solid-Fuel-Burning Appliances and This protection must extend as follows: Equipment before proceeding.

  • Page 11: Residential Installation

    Residential Installation Warning: Under no circumstances is this heater to be installed Chimney and Connector in a makeshift or "temporary" manner. It may be fi red only after the following conditions have been met. Connect to a listed chimney or a chimney suitable for use with solid fuel that is lined and in good condition and meets DO NOT ATTEMPT TO CONNECT THIS HEATER TO local building codes.

  • Page 12: Mobile Home Installation

    FIG. #6 Single Wall Connector - Residential Residential 8" 12" 18" Minimum 20" 12" Clearance to 25 1/2" Combustibles 8" Double Wall Connector - Residential 3" 5" 11" 5" 15" 11" 8" 8" 8" 21 1/2" 21 1/2" 3" Alcove: Min. Height 7' Max.

  • Page 13: Procedure

    Procedure: 4. Cut a hole in the ceiling and roof to suit the chimney system and frame in the sides. The chimney support is mounted to the framing. CAUTION: THE STRUCTURAL INTEGRITY OF THE MO- 5. If the chimney connector exits the mobile home less then BILE HOME FLOOR, WALL AND CEILING/ROOF MUST 7 feet above the ground then a guard must be installed BE MAINTAINED.

  • Page 14: Optional Blower

    Optional Blower The optional blower kit (WODC.BLOW) is equipped with a Optional Outside Air Adaptor three prong power cord and may be installed at any time. Follow installation instructions supplied with the kit. Route The adaptor is only required if the blower kit is to be installed power supply cord away from heater.

  • Page 15: Troubleshooting

    Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet - Use dry wood 2. Turning down air control - Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3.

  • Page 16: Replacement Parts - Neo 1.6

    Replacement Parts - NEO 1.6 (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. 25..Upper Grill ........NE16.5037702 2.... Embossed Panel Set ....NE16.78375XX 3.... Door Catch .......... NE16.7825 26 ..Outside Air Pipe Shield ....... NE16.7872 4....

  • Page 17: Understanding & Operating Your Pacifi C Energy Stove

    Understanding & Operating Your Pacifi c Energy Stove The Pacifi c Energy line of woodstoves is a culmina- ish. This clean charcoal burning stage will last for tion of years of research and development. Designed a considerable length of time and refuelling should to be efficient, clean-burning and user-friendly, this be avoided until the charcoal base has become heater will give you years of warm service.

  • Page 18: Firebrick Installation Instructions

    Firebrick Installation Instructions NEO 1.6 This package contains 13 full-size fi rebricks, as well as 2 various cut-size bricks. With the heater in the upright position, install fi rebricks as follows: - Place 4 full-size fi rebricks at the back of the heater fi rst.

  • Page 19: Label

    Label MUR ADJACENT MUR COTE SIDE WALL ADJACENT WALL COTE SIDE...
  • Page 20 PACIFIC ENERGY FIREPLACE PRODUCTS LTD. 2975 Allenby Rd., Duncan, B.C. V9L 6V8 Phone: 250-748-1184 Web site: http://www.pacifi cenergy.net Printed in Canada...
