IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER

SAFETY NOTICE

If this stove is not properly installed,
a house fire may result. For your
safety, follow the installation
instructions. Contact local building
or fire officials about restrictions
TESTED and LISTED to
ULC S628 / UL 1482
Meets the U.S. Environmental Protection
Agency's May 2015 Particulate Emission
Standards
Visit www. pacificenergy.net for the most up-to-date version of this manual
5055.750
SERIAL #
INSTALLATION
AND OPERATING
INSTRUCTIONS
Model:
NEO 1.6 INSERT
Series: A
310816-32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pacific energy A Series

Summary of Contents for Pacific energy A Series

  • Page 1: Safety Notice

    IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER SERIAL # SAFETY NOTICE INSTALLATION If this stove is not properly installed, a house fire may result. For your AND OPERATING safety, follow the installation instructions. Contact local building INSTRUCTIONS or fire officials about restrictions TESTED and LISTED to ULC S628 / UL 1482 Meets the U.S.

  • Page 2: Table Of Contents

    Table of Contents Rating Label ................4 Maintenance Checks ..............17 Safety ..................5 Weekly ................17 Dimensions ................5 Monthly ................17 Dimensions ............... 5 When Cleaning the Chimney System ......17 Clearances ................. 6 Blower ................17 Masonry or Factory Built Fireplace ........6 Installation ................
  • Page 3 PLEASE SAVE THESE INSTRUCTIONS NOTE: WE STRONGLY RECOMMEND THAT SMOKE DETECTORS BE INSTALLED. If smoke detectors have been previously installed, you may notice that they are operating more frequently. This may be due to curing of stove paint or fumes caused by accidentally leaving the fire door open. Do not disconnect the detectors. If necessary, relocate them to reduce their sensitivity.

  • Page 4: Rating Label

    AUTRES CÔTÉS. CONSTRUCTION INSTALLEZ ET UTILISEZ SELON LES INTRUCTIONS D’INSTALLATION ET D’OPÉRATION DU PACIFIC ENERGY. BÂTIMENT OU POMPIERS LOCAUX DE CONTACT AU SUJET DES CODES, RESTRICTIONS ET D’INSPECTION D’INSTALLATION DANS VOTRE SECTEUR. INSTALLEZ ET EMPLOYEZ SEULEMENT EN MAÇONNERIE OU CHEMINÉE CONSTRUITE PAR USINE.

  • Page 5: Safety

    Safety READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH. We strongly recommend that smoke detectors be installed. If smoke detectors have been previously installed, you may notice that they are operating more frequently. This may be due to curing of stove paint or fumes caused by accidentally leaving the fire door open.

  • Page 6: Clearances

    Clearances Masonry or Factory Built Fireplace The minimum required clearances to surrounding combustible materials when installed into a masonry or factory built fireplace are listed below and shown (Figure 2). Minimum Clearances to Combustibles Adjacent Sidewall .......13 1/2 in. (343 mm) Mantel(measured from top of brow) ..

  • Page 7: Fireplace Hearth Requirements

    Fireplace hearth requirements: (Measured without the insert) The hearth can be flush with an adjacent combustible floor and must extend 16” in front and 8” beyond each side of the fireplace opening. 30” 762mm 20” 508mm 16” 24 3/4” 406mm 629mm 16 1/4”...

  • Page 8: Chimney Smoke And Creosote Formation

    Chimney Smoke and Creosote Formation When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool chimney flue of a slow burning fire. As a result, creosote residue accumulates on the flue lining.

  • Page 9: Operation

    Failure to do so may create a hazardous condition. Your PACIFIC ENERGY heater is designed for many years of trouble free operation. Over firing the appliance will shorten the life of the product. Failure to rectify an over firing condition can be hazardous and may void the manufacturer’s warranty.

  • Page 10: Lighting The Fire

    Lighting the Fire WARNING: Never use chemicals or any other volatile liquid to start a fire. 1. Adjust air control to “High” position (all the way to the left) and open door. 2. Place crumpled newspaper in the center of the heater and criss-cross with several pieces of dry kindling. Add a few small pieces of dry wood on top.

  • Page 11: Restarting After Extended Or Overnight Burns

    Restarting After Extended or Overnight Burns 1. Open door and rake hot embers towards the front of the heater. Add a couple of dry, split logs on top of embers, close door. 2. Adjust air control to “High” position (all the way to the left) and in just a few minutes, logs should begin burning.

  • Page 12: Proper Draft

    Proper Draft 1. Draft is the force which moves air from the appliance up through the chimney. The amount of draft in your chimney depends on the length of the chimney, local geography, nearby obstructions and other factors. 2. Too much draft may cause excessive temperatures in the appliance. An uncontrollable burn or a glowing red stove part or chimney indicates excessive draft.

  • Page 13: Maintenance

    WARNING: Only use materials supplied by the manufacturer when doing maintenance or replacements. 4. DOOR GASKET - The gasket used by Pacific Energy (7/8” medium density fiberglass rope) requires only light pressure to seal. This will prolong seal life. It is important that the door seal be maintained in good condition.

  • Page 14: Blower Maintenance

    7. Establish a routine for the fuel, wood burning and firing technique. Check daily for creosote buildup until experience shows how often you need to be cleaning to be safe. 8. Be aware that the hotter the fire, the less creosote is deposited. Weekly cleaning may be necessary in mild weather, even though monthly cleaning is usually enough in the coldest months when burning rates are higher.

  • Page 15: Blower Replacement

    Blower Replacement 1. Remove the surround front by lifting and pulling away from the unit. Remove the four screws securing the back surround to the brackets and set them aside carefully to avoid damage. 2. Remove the surround mounting bracket by removing the two screws securing the bracket to the side casing of the unit (Figure 5) (may require the unit to be pulled out slightly).

  • Page 16: Power Cord Position

    Power Cord Position The power cord for the NEO 1.6 Insert comes factory set to exit the right side of the unit. If you desire, the cord can be switched to exit to the left of the unit. The cord will lose approximately 12” of length when exit- ing the left side of the unit.

  • Page 17: Maintenance Checks

    Maintenance Checks Check the following parts for damage such as cracks, excessive corrosion, burned out sections and exces- sive warping: (See website for descriptions and more detail) Weekly: • Firebrick - Visual, for cracking. • Door Gasket - sagging, placement, damage. Monthly • Rear brick rail and side brick rails.

  • Page 18: Installation

    Installation Your Insert is designed to be installed into an approved masonry or factory built zero-clearance fireplace. The masonry fireplace must be built according to the requirements of the Standard of Chimneys, Fireplaces, Vents and Solid Fuel Burning appliances, N.F.P.A. 211 (Latest Edition) or applicable National, Provincial, State or local codes.

  • Page 19: Full Flue Liner

    Consult local codes. Pacific Energy highly recommends the use of a full liner as the safest installation and providing opti- mum performance. When connected to a full liner, the Insert is able to draft correctly and will prevent problems such as difficult start-ups and smoking out the door.

  • Page 20: Direct Flue Connection - (Usa Only)

    Direct Flue Connection - (USA only) 1. Measure from the first chimney flue liner to the top of the Insert. Allow extra length of liner to insert into flue tile. 2. Feed the stainless steel liner through the damper area and into the first chimney flue tile. Seal around pipe to the chimney.

  • Page 21: Direct Flue Connection

    Direct flue connection Mantel or Top Facing Chimney Flue Liner 6” Stainless Steel Rigid or Flex Liner Figure 11: Direct flue connection. Into a Factory Built Fireplace Your Insert may be installed into a factory built fireplace (size permitting) with the following requirements: 1.

  • Page 22: Combustion Air

    Combustion Air Consult local building codes regarding combustion air supply. Intake or combustion air can be supplied to the Insert in one of two ways: 1. Outside air supply: Remove cover from ash clean out in existing fi replace. Place a rodent screen in place of the cover.

  • Page 23: Blower

    Blower The Insert comes equipped with variable speed circulating air blowers. The blower system is thermostatically controlled for automatic operation, as well manually with a convenient bypass switch. Blower Operation Automatic: To operate the blower automatically, push the rocker switch to the “0” or AUTO position and set the fan speed control to a desired setting.

  • Page 24: Troubleshooting

    Troubleshooting Problem Cause Cure Excessive Creosote 1) Wood is too wet - Use dry wood(recommended moisture level <20%) Build-up 2) Turning down air control - Do not turn down until: too soon a) there is a good bed of coals b) the wood is charred 3) Draft too low - Chimney plugged or restricted, check flue...

  • Page 25: Neo 1.6 Firebricks

    Neo 1.6 Firebricks This package contains 14 full-size firebricks. For installation instructions, see..Figure 15: Neo 1.6 Insert Firebricks. ITEM SIZE PART NUMBER 9” X 4 1/2” X 1 1/4” (230 mm x 115 mm x 32 mm) 5096.99 NEO 1.6 INSERT-A_310816-32 5055.750...

  • Page 26: Firebrick Installation Instructions

    Firebrick Installation Instructions Figure 16: Empty firebox. Figure 17: Insert rear bricks first. 1. With the firebox empty, insert the rear wall bricks first (Figure 17). Insert the bricks up in behind the tabs and then push the bricks toward the center post so that there is no gap showing between the bricks and the post (Figure 18).
  • Page 27 Figure 20: Lower side brick in position. Figure 21: Side firebrick insertion complete. 3. Once the side bricks (on both sides of the firebox) are installed, push the two horizontal top bricks toward the rear wall of the firebox. This will eliminate any gaps in the corners of the firebox. 4.

  • Page 28: Replacement Parts

    Ashlip ..................NE16.5037701 Brick set................NE16.INSBRIC Flue Collar Handle ..............NE16.78065 Removable Flue Collar w/clamps and gasket ......WODC.7806 22b Flue Collar Gasket ................ 5067.750 Parts can be obtained from your local Pacific Energy dealer using these part numbers. NEO 1.6 INSERT-A_310816-32 5055.750...

  • Page 29: Warranty Information

    Pacific Energy extends the following warranty coverage to the original registered purchaser of the product: 3 Year Comprehensive Pacific Energy will replace or repair any part found to be defective (parts and labor) for three years from the date of pur- chase. This coverage includes electrical components (blowers, speed controls and thermal switches).
  • Page 30 NEO 1.6 INSERT-A_310816-32 5055.750...
  • Page 31 NEO 1.6 INSERT-A_310816-32 5055.750...
  • Page 32 © 2016 Copyright Pacific Energy Fireplace Products LTD. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. PACIFIC ENERGY FIREPLACE PRODUCTS LTD. Phone: 1-250-748-1184 Web site: http://www.pacificenergy.net 2975 Allenby Rd., Duncan, B.C. V9L 6V8...
