IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER
SAFETY NOTICE
If this stove is not properly installed, a
house fire may result. For your safety,
follow the installation instructions.
Contact local building or fire officials
about restrictions and installation
inspection requirements in your area.
TESTED and LISTED to CAN/ULC S627
AND UL 1482
Meets the Environmental Protection
Agency's May 2015 Particulate Emission
Standards
Visit www. pacificenergy.net for the most up-to-date version of this manual
5055.600-A
SERIAL #
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL - NEO 1.2
SERIES - A
NEO 1.2
290816-24
Advertisement
Table of Contents
Related Manuals for Pacific energy NEO 1.2A SERIES
Summary of Contents for Pacific energy NEO 1.2A SERIES
-
Page 1: Safety Notice
IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER SERIAL # INSTALLATION AND OPERATING SAFETY NOTICE INSTRUCTIONS If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions. Contact local building or fire officials about restrictions and installation inspection requirements in your area. -
Page 2: Table Of Contents
Table of Contents Installation Instructions Operator Instructions Rating Label ................3 Stove Dimensions ..............12 Assembly .................. 12 Rating label location ............3 Removing stove from crate ..........12 Efficiency and BTU Output ..........3 Side Panel Installation ............13 Safety .................. -
Page 3: Operator Instructions
Rating Label PLEASE SAVE THESE INSTRUCTIONS This manual describes the installation and operation of the Pacific Energy, NEO 1.2 Freestanding wood heater. This heater meets the 2015 U.S. Environmental Protection Agency's crib wood emission limits for wood heaters sold after May 15, 2015. Model NEO1.2: 2.9 g/hr. -
Page 4: Safety
Operator Instructions Safety Chimney Smoke and Creosote Formation When wood is burned slowly, it produces tar and other organic vapours, which combine with expelled moisture to form creosote. The creosote vapours condense in the relatively cool chimney flue of a slow burning fire. As a result, creosote residue accumulates on the flue lining. -
Page 5: Operation
Keep all such liquids well away from the heater while it is in use. CAUTION: Hot while in operation. Keep children, clothing and furniture away. Contact may cause skin burns. Your PACIFIC ENERGY heater is designed for many years of trouble free operation. Over firing the appliance will shorten the life of the product. -
Page 6: Lighting A Fire
Operator Instructions Lighting a Fire WARNING: Never use chemicals or any other volatile liquid to start a fire. Adjust air control to “High” position (all the way to the left) and open door. Place crumpled newspaper in the centre of the heater and crisscross with several pieces of dry kindling. Add a few small pieces of dry wood on top. -
Page 7: Restarting After Extended Or Overnight Burns
Operator Instructions Restarting After Extended or Overnight Burns Open door and rake hot embers towards the front of the heater. Add a couple of dry, split logs on top of embers, close door. Adjust air control to high and in just a few minutes, logs should begin burning. After wood has charred, reset air control to desired setting. -
Page 8: Maintenance Checks
Operator Instructions Maintenance Checks Check the following parts for damage such as cracks, excessive corrosion, burned out sections and excessive warping: (See website for descriptions and more detail) Some warping of the baffle is normal (up to 1/4” or .65cm). Replace if the baffle has permanent warping greater than this or has signs of cracking or breakage. -
Page 9: Baffle Removal
Follow instructions included in the WODC.DG58 kit obtainable from your nearest Pacific Energy Dealer. 5. DOOR GLASS - Do not slam loading door or otherwise impact glass. When closing door, make sure that no logs protrude to impact the glass. -
Page 10: Troubleshooting
Operator Instructions Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet - Use dry wood 2. Turning down air control - Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3. -
Page 11: Warranty Information
3 Year Comprehensive Pacific Energy will replace or repair any part found to be defective (parts and labor) for three years from the date of purchase. This coverage includes electrical components (blowers, speed controls and thermal switches). -
Page 12: Installation Instructions
Installation Instructions Installation Instructions Stove Dimensions 16 1/2" 27 1/8" 420mm 3 1/2" 688mm 89mm NOTE: DIMENSION DOES NOT INCLUDE 31 3/4" LEVELLING LEGS 807mm 33 1/8" 841mm Figure 1: NEO 1.2 Dimensions. Assembly Removing stove from crate 1. Carefully remove wood top and supports. 2. -
Page 13: Side Panel Installation
Installation Instructions Side Panel Installation 1. Carefully remove the panels from the box. 2. Loosen the panel bracket screws a little so that the bracket can move while fitting the panel into place. 3. Engage the tabs of the panel into the slots in the front mounting bracket (Figure 4). 4. -
Page 14: Residential Installation
Installation Instructions Residential Installation Warning: Under no circumstances is this heater to be installed in a makeshift or "temporary" manner. It may be fired only after the following conditions have been met. • DO NOT ATTEMPT TO CONNECT THIS HEATER TO ANY AIR DISTRIBUTION DUCT. • Outside combustion air or fresh air into the room may be required in your area, consult local building codes (see Combustion Air section). -
Page 15: Procedure
Installation Instructions Procedure If a listed chimney and double-wall connector is to be connected to the stove, install all components to the chimney manufac- turer's installation requirements - (Outside combustion air may be required, consult local building codes. See "Combustion Air"... -
Page 16: Mobile Home Installation
Installation Instructions Mobile Home Installation Warning: Under no circumstances is this heater to be installed in a makeshift or "temporary" manner. It may be fired only after the following conditions have been met. • DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. • DO NOT INSTALL IN A SLEEPING ROOM. -
Page 17: Procedure
Installation Instructions Procedure: CAUTION: THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE MAINTAINED. The services of a competent or certified installer, (certified by the Wood Energy Technical Training program (WETT) - in Canada, Hearth Education Foundation (HEARTH) - in U.S.A.,) are strongly recommended. Note: See "Combustion Air"... -
Page 18: Floor Protector
Installation Instructions Floor Protector The stove may be installed on a combustible floor provided ember protection made from a non-combustible material such as steel, ceramic tile, brick etc.is used. - This protection must extend as follows: In Canada: 18" (457 mm) on the firing side and 8" (203 mm) to the other sides - See Figure 9. U.S.A. -
Page 19: Optional Blower
Installation Instructions Optional Blower The optional blower kit (WODC.BLOW) is equipped with a three prong power cord and may be installed at any time. Follow installation instructions supplied with the kit. Route power supply cord away from heater. Electrical rating: 115 volts A.C., 60Hz, .5 amps. Fan output rating: 125 CFM Blower Operation Proper blower speed matched with air control setting will ensure peak performance from your stove. - Page 20 Installation Instructions Spark arrester rain cap Follow chimney manufacture specifcations for distance between vent termination heigth and chimney at roof line. Also consult local building Certi ed regulations. Chimney Storm collar Roof ashing as per Local Chimney Support and Federal codes The chimney may incorporate Minimum 7' (2.1m.)
- Page 21 Installation Instructions Fireclay Flue liner Concrete cap Ensure that the Masonry chimney meets all National Fire Protection Association and local building codes. Have the chimney cleaned and inspected by a professional to ensure Chimney there are no cracks, weak mortar or other signs of deterioration.
-
Page 22: Neo 1.2 Firebrick Installation Instructions
Installation Instructions NEO 1.2 Firebrick Installation Instructions THIS PACKAGE CONTAINS 6 FULL-SIzE FIREBRICKS AS WELL AS 6 VARIOUS CUT-SIzE BRICKS. WITH THE HEATER IN THE UPRIGHT POSITION, INSTALL FIREBRICKS AS FOLLOWS: • PLACE 4 FULL-SIzE FIREBRICKS AT THE BACK OF THE HEATER FIRST. • NEXT, INSTALL THE SIDE FIREBRICKS, 1 FULL-SIzE AND 1 BRICK "B"... -
Page 23: Replacement Parts - Neo 1.2
Titanium ....TI 9.... Optional Blower ......WODC.BLOW 10 ..Firebrick Set ........NE12.BRIC All parts may be ordered from your nearest Pacific Energy dealer. 11 ..Door Gasket ....NE16.WODC.NEODGKIT 12 ..Baffle Assembly ......PERP787520-A Contact Pacific Energy for the location of the dealer nearest you. - Page 24 © 2016 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. PACIFIC ENERGY PACIFIC ENERGY FIREPLACE PRODUCTS LTD. 2975 Allenby Rd., Duncan, B.C. V9L 6V8 For technical support, please contact your retailer.
