NEC MultiSync FP1370 Service Manual page 73

USER11 VESA 1600*1200@60Hz
TIMING NAME
Pixel Clock 162.000 [MHz]
H.Frequency 75.000 [kHz]
V.Frequency 60.000 [Hz]
H.Tortal Time 2160 [dots] 13.333 [us]
H.Addr Time 1600 [dots] 9.877 [us]
H.Blank Time 560 [dots] 3.457 [us]
H.Front Porch 64 [dots] 0.395 [us]
H.Sync Time 192 [dots] 1.185 [us]
H.Back Porch 304 [dots] 1.877 [us]
V.Tortal Time 1250 [lines] 16.667 [ms]
V.Addr Time 1200 [lines] 16.000 [ms]
V.Blank Time 50 [lines] 0.667 [ms]
V.Front Porch 1 [lines] 0.013 [ms]
V.Sync Time 3 [lines] 0.040 [ms]
V.Back Porch 46 [lines] 0.613 [ms]
Scan Type Non-Interlaced
H.Sync Polarity Positive
V.Sync Polarity Positive
Separate
640*480@160Hz
USER16
TIMING NAME
Pixel Clock 67.200 [MHz]
H.Frequency 80.000 [kHz]
V.Frequency 160.000 [Hz]
H.Tortal Time 840 [dots] 12.500 [us]
H.Addr Time 640 [dots] 9.524 [us]
H.Blank Time 200 [dots] 2.976 [us]
H.Front Porch 16 [dots] 0.238 [us]
H.Sync Time 64 [dots] 0.952 [us]
H.Back Porch 120 [dots] 1.786 [us]
V.Tortal Time 500 [lines] 6.250 [ms]
V.Addr Time 480 [lines] 6.000 [ms]
V.Blank Time 20 [lines] 0.250 [ms]
V.Front Porch 1 [lines] 0.013 [ms]
V.Sync Time 3 [lines] 0.038 [ms]
V.Back Porch 16 [lines] 0.200 [ms]
Scan Type Non-Interlaced
H.Sync Polarity Negative
V.Sync Polarity Negative
Separate
USER12 1280*1024@70Hz USER13 VESA1152*864@85Hz
127.000 [MHz]
74.970 [kHz]
69.870 [Hz]
1694 [dots] 13.339 [us] 1576 [dots]
1280 [dots] 10.079 [us] 1152 [dots]
414 [dots] 3.260 [us] 424 [dots]
30 [dots] 0.236 [us] 64 [dots]
160 [dots] 1.260 [us] 128 [dots]
224 [dots] 1.764 [us] 232 [dots]
1073 [lines] 14.312 [ms] 907 [lines] 11.765 [ms]
1024 [lines] 13.659 [ms] 864 [lines] 11.207 [ms]
49 [lines] 0.654 [ms] 43 [lines]
3 [lines] 0.040 [ms]
4 [lines] 0.053 [ms]
42 [lines] 0.560 [ms] 39 [lines]
Non-interlaced
Negative
Negative
Sync on G
USER17 VESA 1920*1440@60Hz USER18 VESA 1600*1200@70Hz USER19
234.000 [MHz]
90.000 [kHz]
60.000 [Hz]
2600 [dots] 11.111 [us] 2160 [dots]
1920 [dots] 8.205 [us] 1600 [dots]
680 [dots] 2.906 [us] 560 [dots]
128 [dots] 0.547 [us] 64 [dots]
208 [dots] 0.889 [us] 192 [dots]
344 [dots] 1.470 [us] 304 [dots]
1500 [lines] 16.667 [ms] 1250 [lines] 14.286 [ms]
1440 [lines] 16.000 [ms] 1200 [lines] 13.714 [ms]
60 [lines] 0.667 [ms] 50 [lines]
1 [lines] 0.011 [ms]
3 [lines] 0.033 [ms]
56 [lines] 0.622 [ms] 46 [lines]
Non-interlaced
Negative
Positive
Separate
USER14 1024*768@100Hz
121.500 [MHz]
77.094 [kHz]
84.999 [Hz]
12.971 [us] 1344 [dots]
9.481 [us] 1024 [dots]
3.490 [us] 320 [dots]
0.527 [us] 24 [dots]
1.053 [us] 136 [dots]
1.909 [us] 160 [dots]
806 [lines]
768 [lines]
0.558 [ms] 38 [lines]
1 [lines] 0.013 [ms] 3 [lines]
3 [lines] 0.039 [ms] 6 [lines]
0.506 [ms] 29 [lines]
Non-Interlaced
Positive
Positive
Separate
800*600@140Hz
189.000 [MHz]
87.500 [kHz]
70.000 [Hz]
11.429 [us] 1055 [dots]
8.466 [us] 799 [dots]
2.963 [us] 256 [dots]
0.339 [us] 16 [dots]
1.016 [us] 80 [dots]
1.608 [us] 160 [dots]
625 [lines]
600 [lines]
0.571 [ms] 25 [lines]
1 [lines] 0.011 [ms] 1 [lines]
3 [lines] 0.034 [ms] 3 [lines]
0.526 [ms] 21 [lines]
Non-Interlaced
Positive
Positive
Separate
USER15 800*600@120Hz
108.390 [MHz] 83.250 [MHz]
80.647 [kHz] 78.835 [kHz]
100.059 [Hz] 121.659 [Hz]
12.400 [us] 1056 [dots] 12.685 [us]
9.447 [us] 800 [dots] 9.610 [us]
2.952 [us] 256 [dots] 3.075 [us]
0.221 [us] 32 [dots] 0.384 [us]
1.255 [us] 80 [dots] 0.961 [us]
1.476 [us] 144 [dots] 1.730 [us]
9.994 [ms] 648 [lines] 8.220 [ms]
9.523 [ms] 600 [lines] 7.611 [ms]
0.471 [ms] 48 [lines] 0.609 [ms]
0.037 [ms] 2 [lines] 0.025 [ms]
0.074 [ms] 4 [lines] 0.051 [ms]
0.360 [ms] 42 [lines] 0.533 [ms]
Non-Interlaced Non-interlaced
Positive Positive
Positive Positive
Separate Separate
USER20 VESA 1792*1344@75Hz
92.300 [MHz] 261.000 [MHz]
87.488 [kHz] 106.270 [kHz]
139.981 [Hz] 74.997 [Hz]
11.430 [us] 2456 [dots] 9.410 [us]
8.657 [us] 1792 [dots] 6.866 [us]
2.774 [us] 664 [dots] 2.544 [us]
0.173 [us] 96 [dots] 0.368 [us]
0.867 [us] 216 [dots] 0.828 [us]
1.733 [us] 352 [dots] 1.349 [us]
7.144 [ms] 1417 [lines] 13.334 [ms]
6.858 [ms] 1344 [lines] 12.647 [ms]
0.286 [ms] 73 [lines] 0.687 [ms]
0.011 [ms] 1 [lines] 0.009 [ms]
0.034 [ms] 3 [lines] 0.028 [ms]
0.240 [ms] 69 [lines] 0.649 [ms]
Non-interlaced Non-Interlaced
Positive Negative
Positive Positive
Separate Separate
