Multitone FLA 872 Technical Manual page 70

TLA 852/FLA 872
DESCRIPTION
1p ±0.25% 50V
3p9 ±0.25p 50V
4p7 ± 0p25 50V
6p8 50V
8p2 50V
10p ±0p5 50V
ITEM/CIRCUIT
REFERENCE
6.3.3 Crystal and Filters
FL401
FL402, 403
FL402, 403
FL404
XL401
XL402
XL402
XL403
6.3.4 Inductors
CCT REF
L401
L406, 410
L407
L408
L409
L416
L417
L418
DESCRIPTION
2µ2 ±10%
39n ±10%
47n ±10%
56n ±10%
68n ±10%
82n ±10%
ITEM/CIRCUIT
Page 6 - 4
PART No.
3326-0015
3326-0010
3326-0011
3326-0013
3326-0014
3326-0015
DESCRIPTION
CRYSTAL FILTER 21.4MHz
CERAMIC FILTER, SMD, 10/12.5kHz
CERAMIC FILTER, SMD, 20/25kHz
FILTER CHIP CDBC455CX25-TC
CRYSTAL 20.945MHz
CRYSTAL, GENERIC SPEC
CRYSTAL, GENERIC SPEC
MICRO CRYSTAL MX1V-TL 76.8 kHz
* QUOTE CHANNEL FREQUENCY TO SIX DECIMAL PLACES
Band 1 Band 2 Band 3
82n 82n
2µ2 2µ2
100n 100n
330n 330n
560n 560n
68n 68n
47n 47n
N/F N/F
PART No.
4103-0233
4117-0017
4117-0018
4117-0019
4117-0020
4117-0021
DESCRIPTION
12p ±5% 50V
15p ±0p5 50V
18p ±0p5 50V
100p ±5% 50V
LINK (RES CHIP 0S)
Band 4 Band 5
68n 68n 68n
2µ2 2µ2 2µ2
100n 100n 100n
270n 270n 270n
470n 470n 390n
56n 56n 47n
39n 39n 33n
N/F N/F N/F
DESCRIPTION
100n ±5%
270n ±5%
330n ±5%
390n ±5%
470n ±5%
560n ±5%
PART No.
3326-0016
3326-0017
3326-0018
3326-0027
3115-0001
PART No.
4001-0025
4018-0004
4018-0002
4003-0005
3915-0017
3948-*
3950-*
3922-0012
Band 6
56n
2µ2
100n
270n
390n
47n
33n
N/F
PART No.
4103-0254
4103-0264
4103-0266
4103-0268
4103-0270
4103-0272
TM1205 Issue 2
