2.4

LOW BATTERY

2.4.1

Low Battery Warning

When the battery needs replacing, the pager sounds an alert and the low battery
symbol shows on the standby screen.
2.4.2

Replacing the Battery

a) Refer to Figure 2.4. Use a thumbnail to press down on the battery door lock on
the back of the unit. Hold the door lock down and push the battery door in the
direction shown. Rotate the door as shown in Figure 2.4 to gain access to the
battery.
b) Remove the old battery.
c) Refer to the diagram in the battery compartment and install the new battery.
SLIDE THE BATTERY DOOR
FORWARD
TM1205 Issue 2
A
PUSH THE DOOR LOCK TO
RELEASE THE BATTERY DOOR
Figure 2.4: Opening the Battery Door
TLA 852/FLA 872
B
PUSH THE LONG EDGE OF THE
BATTERY DOOR UPWARDS TO OPEN IT
TAG11126-1
Page 2 - 15
