Multitone FLA 872 Technical Manual page 60

TLA 852/FLA 872
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Page 5 - 20
Table 5.6: IC4 RAM Pin Connections
Pin Name
A14
A12
A7
A6
A5
A4
A3
A2
A1
A0
D0
D1
D2
VSS
D3
D4
D5
D6
D7
CE
A10
OE
A11
A9
A8
A13
WE
VDD
Description
Address line AD14
Address line AD12
Address line AD07
Address line AD06
Address line AD05
Address line AD04
Address line AD03
Address line AD02
Address line AD01
Address line AD00
Data line D00
Data line D01
Data line D02
Ground
Data line D03
Data line D04
Data line D05
Data line D06
Data line D07
RAM-CE - chip enable input
Address line AD10
Ground
Address line AD11
Address line AD09
Address line AD08
Address line AD13
WR - RAM read/write control
VDD
TM1205 Issue 2
