Multitone FLA 872 Technical Manual page 55

DEVICE COLLECTOR
TR1 3.00
TR2 -
TR3 1.4
TR4 1.4
C5 0.19dc
R1/C4 3.00
R35 1.49dc
IC402 pin9 1.49dc
IC5 3.00 (pin 1)
IC6 1.4 (pin 1)
STEP
1
2
3
TM1205 Issue 2
Table 5.3: Decoder Board DC Levels
BASE
3.00
3.00
-
-
2.2 V p-p
3.0V p-p
3.0V p-p
3.00 (pin 2)
3.00 (pin 2)
Table 5.4: Decoder Board Test Sequence
TEST POINT
R23 VDD
R35 38.4kHz POCSAG Clock
R1 4.19MHz Microprocessor Clock (every 500ms)
EMITTER
1.4 Battery Disconnect Monitor
1.4 Backlight Driver
- Vibrate Enable
- Vibrate Motor Drive
4ms wide XL2 4.19MHz
CLKO 38.4kHz
XL403 38.4kHz (Radio Board)
0 (pin 3) Reset
1.4 (pin 5) VDD Supply
REMARKS
TLA 852/FLA 872
REMARKS
Page 5 - 15
