Controls And Indicators - Multitone FLA 872 Technical Manual

DO NOT TAKE THE PAGER INTO AREAS WHERE EXPLOSIVE GASES, OR
DUST MAY BE PRESENT.
PROTECT THE PAGER FROM LIQUIDS, STRONG MAGNETIC FIELDS AND
EXTREME TEMPERATURES. DO NOT LEAVE THE PAGER EXPOSED TO
STRONG SUNLIGHT.
2.1

CONTROLS AND INDICATORS

Refer to Figure 2.1 for the identification and location of the controls and display
associated with the TLA 852 and FLA 872.
Note: In Germany, Style A (aerofoil) case is only for T Mobile use.
In the United Kingdom, Style B (oval) case is only for use by Vodafone Paging.
>
CONTROL BUTTONS
TM1205 Issue 2
WARNING
CAUTION
DISPLAY
CONTROL BUTTONS
STYLE A
Figure 2.1: Controls and Display
TLA 852/FLA 872
DISPLAY
STYLE B
TAG11268
Page 2 - 3
