SIG SIGRC80 Rascal C Instruction Book page 3

.
Sheet Balsa
2 1/16"x3"x36" Balsa Sheet (Fuselage)
Hardwood
1 3/16"x3/16"x3" Elevator Joiner
(Spruce)
Shaped Balsa
2 24" Long Shaped Leading Edge
Hardware
8 2-56x3/8" Slotted Bolts (Wheel Pant
Mounts & Motor Mount)
2 3/32" Dia. x3" Aluminum Tube
(Fuselage Cabin Braces)
2 #2x3/8" Sheet Metal Screws (Hatch
Mount)
Pre-Bent Music Wire
1 3/32" Dia. Pre-Bent Main Gear Wire
Plastic Parts
1 Set of .030 Molded Wheel Pants
Miscellaneous
3 .031x18" Steel Cable (Throttle, Rudder
& Elevator)
1 19"x25" Full Size Plan Sheet 1
1 5"x13-1/2" Decal Sheet
Items Needed To Complete Kit
Electric Version
Speed 400 Motor and Gearbox - Maxx #ACC347
7 or 8-cell 600 AE Battery Pack with Connectors
Speed Controller for 7-8 Cells
Battery Pack Charger - A/C-D/C Type
Battery Connectors, such as Sermos
16 gauge red & white hook-up wire
Electric Motor Mount - Maxx #ACC314
Glow Engine Version
.049 - .07 R/C Engine
Sullivan 2 ounce Slant Fuel Tank, #SS-2 436
Third Servo for Throttle Control
250 - 350 maH Airborne Battery Pack
Dave Brown #0506 Motor Mount
Small Diameter Fuel Tubing
Common To Both Versons
Radio System with small micro or mini servos and a small receiver
Covering Material - Two 6 rolls typical for multi-color scheme
Williams Bros. 1-7/8 diameter wheels - #150
Typical Hobby Tools: Hobby knife with sharp blades, Dremel Tool and bits, selection of drill bits, razor blades,
sandpaper, and sanding blocks of various sizes, pliers, good soldering iron and solder, etc.
2 5/32" Dia. x1-1/4" Wing Dowels
1 2" Long Shaped Wing Center
Section Block
8 2-56 Blind Nuts (Wheel Pants &
Motor Mount)
1 1/16" Dia. x1/2" Aluminum Tube
(Tail Skid Brace)
2 Gem #1 Paper Clips (P/R
Connectors)
1 1/32" Dia. Pre-Bent Tail Skid
1 .008x3"x17" Clear Plastic For
Windshield & Side Windows
3 .073 O.D.x18" Nylon Tube (Throttle,
Rudder & Elevator)
1 19"x25" Full Size Plan Sheet 2
1 Printed Instrument Panel
7 1/16"x1/4"x1" Tapered T.E.
Stock (Shims)
1 8-32x1" Nylon Wing Bolt
1 5/16" Dia. x1/4" Drilled Wing
Dowel
1 2-1/2"x4-1/4" Card Stock
(Main Gear Fairings)
1 19"x25" Full Size Plan Sheet 3
1 Photo-Illustrated Instruction
Book
4 1/16" Dia. x1/4" Brass
Tube (Pushrods)
2 3/32" Landing Gear Clips
1 1"x4-1/4" Velcro (Battery
Hold Down)
1 9-1/2"x25" Full Size Plan
Sheet 4
