- Page 2 E Aristocrats remain flying and are highly valued by their owners and Waco enthusiasts alike. The SIG 1/6th scale Waco SRE ARF kit is a very nice tribute to the exquisite lines and high-performance capabilities of its full-scale counterpart. Based on the full-scale NC1252W SRE, the SIG Waco shares its beautiful color scheme and undeniably Waco lines.
- Page 3 ENGINE SELECTION: (7) standard servos. Also, we chose to replace the typical 500 – The SIG Waco SRE ARF model is designed to be powered by glow 600maH airborne NiCad battery pack for a larger after-market engines in the following types and size ranges: 1100maH pack.
- Page 4 Therefore, be assured that your kit has been checked and was shipped with all of the listed parts included. Missing The SIG Waco SRE ARF kits are built and covered in a part of the part claims made after the assembly of the model begins world that is typically humid.
- Page 5 Bag #1 Bottom Wing - Covered and trimmed with AeroKote ® 1 each Nylon Strap - Main landing gear wire • 4-40 blind mounting nuts installed for N-struts - retainer for nylon block 2 on each side 2 each Nylon 4mm Main Landing Gear Wire •...
- Page 6 1 each Front Clamp Sub bag C: 1 each Rear Clamp, threaded 4 each M2 x 15 mm Phillips Head bolts - rudder 1 each M3 x 20mm Clamp Compression Bolt & elevator control horns 1 each Fuel Pick-Up Weight 8 each T2.6 x 12 mm PWA Screws - flap &...
- Page 7 ASSEMBLY: Top Wing Panels: As received in the kit, both of the top wing panels have the ailerons WINGS: and flaps in place with the appropriate hinges. Note that these hinges are NOT glued in place. In the following steps, you will be Bottom Wing: required to test the movement of the aileron and flap servos with The bottom wing has been completely built and covered at the...
- Page 8 10 minutes before flexing the aileron. Any excess glue on the accurately place and center the hinges equally into both the wing surrounding covering can be quickly removed with SIG Debonder. panel and the aileron. To do this, use a business card and pair of scissors to cut four "wedges".
- Page 9 your servos, mount the servo in place. Install the opposite aileron Pushrods (2-1/2" long with a metal clevis at one end and a Z-bend servo in the same manner. Last, use a small piece of tape to at the other). Locate Bag #21 and remove four (4) Nylon Control identify the two servo leads as the aileron leads.
- Page 10 motion moves the output arms towards the flap, reverse the flap The transmitter can now be used to test the flaps. If necessary, channel through the transmitter. With the servos now moving in the adjust the clevises to neutralize the flaps at zero, or no-flap. Now correct directions and the output arms in place correctly, linkages test the flap movement with the transmitter.
- Page 11 wing panels. Use four 4-40 x 9 mm round head Allen bolts to install the four brackets, using thread-locking compound on the bolt threads. As you did when mounting the flap horns, use a #57 (.043”) dia. bit to now drill two parallel and perpendicular into the aileron at the marks just made, about 3/8”...
- Page 12 (we used a #58, .042" dia.) up with water. We used SIG Super-Weld liquid resin glue for this to drill four pilot holes for the servo screws. Reinstall the rudder job.
- Page 13 the model from the front and rear, making sure the fin is visually aligned. Any excess glue is easily removed with a clean paper towel and water. Allow the glue to dry. 5) The elevators are now hinged to the horizontal stabilizer, using the hinging methods described earlier for the flaps and ailerons.
- Page 14 Trial-fit the tailwheel wire into the bottom leading edge of the rudder at this time. It may be necessary to deepen the After sufficient time has passed, briskly flex the rudder left and right to free up its movement. Any excess glue can be removed with SIG Debonder.
- Page 15 11) The tailwheel mounting bracket is now mounted in place to the bottom rear of the fuselage using the three provided T2.6 x 10 mm Phillips head screws. Visually center the bracket in place and use a sharp pencil to mark the mounting hole locations onto the fuselage.
- Page 16 transmitter to correct this. Now fit the rudder output arm onto the 14) The final pull-pull rudder connections are now made at the servo, aligning it at 180 to the servo body. If it will not fit at the two rudder control horns. Use a piece of masking tape at the position, try reversing it on the output shaft.
- Page 17 NOT mount your engine on these motor mounts by drilling and tapping them for bolts or screws! These mounts should be drilled for clearance of the engine mounting bolts and the engine itself should be secured to the mount arms with bolts, washers and lock nuts.
- Page 18 3) The engine mounting bolt holes are now drilled through the then through the corresponding hole in the firewall. Engage the two mount arms. These four holes should be clearance holes for threads of the blind nut being held in place and begin threading it the bolts you intend to use.
- Page 19 down in the servo tray with its output arm facing inward towards the center of the cabin, as shown. This servo is installed into the opening that is on the same side as the carburetor throttle arm. Prepare the throttle servo by first installing the rubber grommets and eyelets into its mounting lugs.
- Page 20 servo output arm retaining screw. Install the M2 threaded clevis with its M2 x 22 mm threaded stud in place into the outermost hole in the servo output arm. Place the arm back onto the servo at the full "high" throttle position - about 45 back from center and also hold the nylon pushrod at the full "high"...
- Page 21 Doing this now avoids any confusion later when connecting the fuel FUEL TANK INSTALLATION: lines to their proper locations on the fueling valve and/or engine. 1) The completed fuel tank is now installed into the nose of the model. As mentioned earlier, the fuel tank has an offset neck. The correct orientation of the tank in the tank compartment is with the neck "up"...
- Page 22 1) With the fuselage sitting upright on your work surface, try 3) Once the cowl fits nicely in place, use pieces of tape to first fitting the cowl over the engine and back onto the fuselage. In hold it onto the fuselage. What you want to see is the black stripes the case of our Saito 1.00, we found that the two valve covers on the cowl lining up with those on the fuselage and that, in side at the top of the engine head prevented the cowl from fitting...
- Page 23 With the simple two-line fuel system shown in this manual, these two parts create a very neat and efficient fueling system. The SIG Fueling Valve Bracket allows the fuel valve to be mounted to the firewall.
- Page 24 measurement was 1-5/16”). Reinstall the cowl onto the fuselage. Our reason for using this part was to neatly and efficiently redirect the exhaust back to the stock muffler that we mounted into the c) Lay a ruler on the side of the fuselage, centered over the bottom center recessed opening at the nose of the fuselage.
- Page 25 c) The flex tube header can now be bent into the desired hole 1/4" away from the half circle cut out, on each side. Center configuration. This tube bends surprisingly well and will hold its these holes exactly in the center of the lite-ply and drill them both shape provided you over-bend it a little.
- Page 26 metal hose clamp to hold it in place to the muffler. The diverter OPTIONAL GLOW DRIVER INSTALLATION: itself is slotted at one end, allowing the clamp to compress it firmly to the muffler. Note that in the case of the Saito cast As mentioned earlier, we chose to install an after-market glow aluminum muffler (described earlier), the small, machined ridge at driver system in our Waco models.
- Page 27 As shown, this installation requires a small hole to be drilled assembly is black, it becomes virtually invisible when in place. Use through the firewall to provide an opening for the glow plug the backplate provided with the switch as a cutting template for the connector wire and the ground wire.
- Page 28 secure it in place. As shown, we drilled two small holes in the on each center window former. servo tray to better fit and tighten the zip-tie. We located the programming button on the bottom side of the box, allowing us to re-program it if that ever became necessary.
- Page 29 gear is installed with the small holes - one on each leg - located to the rear of the fuselage. Use thread locking compound on each 8-32 bolt and tighten the four mounting bolts firmly. 1) Turn the fuselage over, upside down on your padded work surface.
- Page 30 At the main landing gear legs, the forward ends of rear support in place onto one of the axles. Locate it immediately next to the struts intersect the small hole pre-drilled in each landing gear leg. main landing gear leg with its setscrew pointing straight down. Note that these support struts are mounted to the inside of the Tighten its setscrew just enough to hold it in place.
- Page 31 We suggest the following procedure to accurately apply the larger decals in this kit. Carefully cut out the decal and lift it off the sheet with tweezers. Use a product like SIG Pure Magic Model Airplane Cleaner or Windex ®...
- Page 32 The SIG 4” Epoxy Spreader - #SIGSH678 - is perfect for this job. Remove any excess fluid with a dry paper towel and allow the decals to set overnight. They will be solidly adhered to the model without any air bubbles.
- Page 33 Repeat this process with the remaining seven turnbuckles, cables, and swages. You should now have eight turnbuckles with the flying wires attached and locked in place. 3) All eight turnbuckles, with the flying wires attached, are now mounted to the bottom surfaces of the two top wing panels, using eight of the provided T2.6 x 8 mm PWA screws.
- Page 34 8) The top fuselage access hatch can now be reinstalled in place using the two T2.6 x 8 mm PWA screws. If your cowl is not in place on the model, reinstall it now. 9) From the kit contents, locate Bag #16, the aluminum scale spinner.
- Page 35 CENTER OF GRAVITY: be corrected. Establishing the correct Center of Gravity (C.G.) for this or any R/C In the case of a model that balances nose heavy, the correction to model aircraft is critical to its ultimate success in the air. Measured make it balance level is fairly easy.
- Page 36 Make it a routine part of your pre-flight procedures to check each If your transmitter uses a toggle type flap switch and you have control on the airplane, making sure each flight surface is moving set-up your flaps as suggested in this manual, then you should in the correct direction.
- Page 37 In our experience, we've found that most anything on a new model that SIG Manufacturing sincerely hopes that you continue to enjoy your can come loose or fail will almost always show up during the first Waco SRE ARF model for a long time to come.
- Page 38 AMA WEB SITE: modelaircraft.org CUSTOMER SERVICE SIG MANUFACTURING COMPANY, INC. is committed to your success in both assembling and flying the WACO SRE ARF kit. Should you encounter any problem building this kit, or discover any missing or damaged parts, please feel free to contact us by mail or telephone.
