Quick Jumper Settings
JP12: Clear CMOS data
JP9: S/PDIF Output Level Selection
On: 5Vp-p (TTL)
Off: 0.5Vp-p (75 ohm load)
®
WinFast
Audio Connector 1
Audio Connector 2
Aux Audio Connector
Hard Disk (Primary IDE)
Hard Disk (Secondary IDE)
ATX Power Connector
Floppy Disk
Normal
Clear CMOS data
6000ABX User's Manual
