Quick Jumper /Connector - Leadtek WinFast 6000ABX User Manual

Leadtek Research Inc.
Quick Jumper/Connector Description
Jumper
SW1(2), SW1(3), SW1(4), SW1(5) CPU Core/Bus Ratio Selection
JP12
JP9
Connector
JP4, JP5
JP20
FIR/SIR
CPUFAN
JP13
J1
J2
J3
P1
SYSFAN
4
Description
Clear CMOS Data
S/PDIF Output Level Selection
Description
S/PDIF Input (JP4), S/PDIF Output (JP5)
PWRBTN, RESET, KEY_LOCK, SPEAKER,
HDD_LED, PPWER_LED
IR Connector
CPU Fan
Wake-On-LAN
PS/2 Mouse (top), PS/2 Keyoard (bottom)
USB1, USB2
Printer, COM1, COM2
Midi/Joystick, Mic In, Line In/Rear 2 Speaker Out,
Line Out 1
System Fan
