Sun Server X2-4 Components and Capabilities (Continued)
TABLE 1-1
Component
PCI Express I/O cards
Ethernet ports
Service processor
Power supplies
Cooling fans
Management software
1.2

Server Front Panel Features

FIGURE 1-5
Sun Server X2-4
For a list of I/O cards that are customer-orderable options, go to the Sun x86
Servers web site and navigate to the Sun Server X2-4 page:
http://www.oracle.com/technetwork/server-storage/sun-x8
6/overview/index.html
Four 10/100/1000 RJ-45 GbE ports on rear panel.
Each Network Interface Controller (NIC) supports Intel QuickData Technology,
Intel I/OAT, VMDq, PCI-SIG SR-IOV, IPSec offload, and LinkSec.
Integrated Baseboard Management Controller (BMC), which supports the
industry-standard IPMI feature set.
Supports remote KVMs, DVD, and floppy over IP (optional license required).
Includes serial port.
Supports Ethernet access to SP through a dedicated 10/100BaseT management
port and optionally through one of the host GbE ports (sideband management).
Two hot-swappable power supplies, each with 2000 Watts capacity (from 200 Volts
to 240 Volts), auto-ranging, light load efficiency mode and redundant
over-subscription.
Six hot-swappable, redundant fans at chassis front (top-loading); redundant fans
at each power supply.
Oracle Integrated Lights Out Manager (ILOM)
shows the Sun Server X2-4 front panel and describes its components.
Chapter 1 Sun Server X2-4 Service Manual Overview 1-9
