Sun Netra X6270 M2 Server Module
Getting Started Guide
This guide describes the minimum steps you must perform to power on Oracle's Sun Netra X6270 M2 server
module for the first time.
Additional installation information is provided in the Sun Netra X6270 M2 Server Module Installation
Guide (821-0937) and in the installation guide for the modular system (chassis). This documentation is available
at the Sun documentation web site. See
Note –
Before installing this server module, read the latest Sun Netra X6270 M2 Server Module Product Notes
(820-2383) to find out if any late-breaking issues impact installation requirements.
▼ Install Optional Components
♦
Before installing the server into the modular system chassis, install any optional components that you
ordered with the server, such as storage drives, DIMMs, REMs, FEMs, and so on.
Refer to the online Sun Netra X6270 M2 Server Module Installation Guide.
▼ Install the Server Module
You can insert the server module into a chassis that is either powered on or not powered on. For information
about powering on the modular system chassis, refer to the modular system documentation.
The following procedure assumes the chassis is powered on.
1. Verify that the system chassis is powered on.
When the chassis is powered on, the fans are operating and the OK LED illuminates a steady on green light.
2. From the front of the chassis, locate and remove the filler panel from the slot where you plan to insert the
server module.
Pull the lever out and eject the filler panel.
3. Position the server module vertically with the ejectors extended and oriented on the right.
4. Push the server module into the slot until the server module stops and is even with the chassis.
"Documentation for This Product" on page
5.
1
Advertisement
Table of Contents
Related Manuals for Sun Oracle Netra X6270
Summary of Contents for Sun Oracle Netra X6270
-
Page 1: Getting Started Guide
Sun Netra X6270 M2 Server Module Getting Started Guide This guide describes the minimum steps you must perform to power on Oracle’s Sun Netra X6270 M2 server module for the first time. Additional installation information is provided in the Sun Netra X6270 M2 Server Module Installation Guide (821-0937) and in the installation guide for the modular system (chassis). - Page 2 ILOM on the server module in different ways as described in the following figure and table. Instructions in this guide use method 1. To use the other methods, refer to the Sun Netra X6270 M2 Server Module Installation Guide and the Oracle Integrated Lights Out Manager (ILOM) 3.0 documentation collection.
- Page 3 (Connection Type) Method From Description (Ethernet) (Method used in this guide) CMM NET MGT Your network Ensure that the CMM NET MGT port is connected to your network. port From your network, log into ILOM on the CMM using the IP address of the CMM.
- Page 4 2. Log into the CMM with the SSH client. In the following example, replace 10.3.212.24 with the IP address of your CMM. Specify the password that is assigned to the CMM ILOM root account. The factory default ILOM root password is changeme. Example: $ ssh root@10.3.212.24 Password: cmm_ILOM_password Oracle(TM) Integrated Lights Out Manager...
- Page 5 Install the latest versions for the best performance, security, and stability. 1. Review the Sun Netra X6270 M2 Server Module Product Notes at: http://docs.sun.com/app/docs/prod/nt6270.m2.srvrmod?l=en#hic The product notes provide a list of supported OSs, describes important product dependencies, and lists any late breaking information.
-
Page 6: Other Product Documentation
Sun Netra X6270 M2 Server Module Getting Started Guide, part number 821-2123-10 Copyright © 2010, Oracle and/or its affiliates. All rights reserved. Copyright © 2010, Oracle et/ou ses affiliés. Tous droits réservés.
