Sun Blade X6270 M2 Server Module
Getting Started Guide
This guide describes the minimum steps you must perform to power on and configure your Sun Blade X6270 M2
Server Module for the first time.
Detailed installation information can be found in the Sun Blade X6270 M2 Server Module Installation Guide, which
is available at the Oracle documentation web site:
http://docs.sun.com/app/docs/prod/blade.x6270m2#hic
Contents
Oracle's Sun Blade X6270 M2 Server Module is shipped with safety documentation and the components that you
ordered for your configuration. Optional components might be packaged and shipped separately.
Documentation and Media Kit
The Documentation and Media Kit is an orderable option for your system. It contains installation
documentation, the Tools and Drivers DVD, the Oracle Hardware Installation Assistant CD, and the Oracle
SunVTS CD. You can order the Documentation and Media Kit at any time, using the following marketing part
number: X6270-X-MEDDOCKIT.
You also can download the documentation and software that are included in the Documentation and Media Kit
from these sites.
For documentation:
■
For software:
http://www.oracle.com/goto/x6270m2
■
Safety and Compliance Information
Before performing an installation, refer to the following documents for safety information regarding the
Sun Blade X6270 M2 Server Module:
Important Safety Information for Sun Hardware Systems – Printed document included in the ship kit.
■
Sun Blade X6270 Server Module Safety and Compliance Manual – Online at the Oracle documentation site.
■
▼ Install Optional Components
Before installing the server into the chassis, you must first install any optional components that you ordered
with the server, and that were not factory installed. Refer to the Sun Blade X6270 M2 Server Module Service Manual
for the instructions on installing optional components.
http://docs.sun.com/app/docs/prod/blade.x6270m2#hic
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sun Blade X6270 M2 and is the answer not in the manual?

Questions and answers

Related Manuals for Sun Oracle Sun Blade X6270 M2

Summary of Contents for Sun Oracle Sun Blade X6270 M2

  • Page 1 Before installing the server into the chassis, you must first install any optional components that you ordered with the server, and that were not factory installed. Refer to the Sun Blade X6270 M2 Server Module Service Manual for the instructions on installing optional components.

  • Page 2: Install Server Module And Verify Standby Power State

    STANDBY power from the powered-on system chassis. For information about powering on the system chassis, refer to the system chassis documentation. For more information about powering on the server module, refer to the Sun Blade X6270 M2 Server Module Installation Guide. The following procedure assumes the chassis is powered-on.
  • Page 3 You can connect to ILOM using one of the methods listed in the following table. (Connection Type) Method From Description (Ethernet) Your network Ensure that the chassis monitoring module (CMM) NET MGT port is connected to your network. CMM NET MGT port From your network, log in to ILOM on the CMM or the server module using the IP address of the CMM or server module.

  • Page 4: Power On The Server Module Host

    ▼ View or Change Network Settings Using the ILOM CLI By default, the server module SP uses a Dynamic Host Configuration Protocol (DHCP) server for network configuration of IPv4 networks and an IPv6 router for network configuration of IPv6 networks. To view the default network settings using the ILOM CLI: 1.

  • Page 5: Set Up The Platform Operating System And Driver Software

    For installation information, Installation For patch information, system: Read this document: go to: Assistant, go to: go to: Preinstalled Sun Blade X6270 M2 Server • See the Sun Blade X6270 http:// • http:// operating Module Installation Guide M2 Server Module www.oracle.com/ www.oracle.

  • Page 6: Accessing Documentation

    Please include the title and part number of your document with your feedback: Sun Blade X6270 M2 Server Module Getting Started Guide, part number 821-0494-13 Copyright © 2010, Oracle and/or its affiliates. All rights reserved. Copyright © 2010, Oracle et/ou ses affiliés. Tous droits réservés.
