GV-POE0800
8-Port 10M/100M PoE Fast Ethernet Switch
Packing List
Before you start to install, please verify that your package contains the following items:
1. GV-POE0800 x 1
2. Screw x 8
3. Rack Mount Kit x 1
4. AC Power Cord x 1
5. User's Manual CD x 1
6. GV-POE0800 Quick Start Guide x 1
Note: If any of these items is found missing or damaged, please contact your local
supplier for replacement.
Front Panel
April 2, 2013
8-Port 130W 802.3at PoE Switch
1
Advertisement
Related Manuals for GeoVision GV-POE0800
Summary of Contents for GeoVision GV-POE0800
-
Page 1: Packing List
3. Rack Mount Kit x 1 4. AC Power Cord x 1 5. User’s Manual CD x 1 6. GV-POE0800 Quick Start Guide x 1 Note: If any of these items is found missing or damaged, please contact your local supplier for replacement. -
Page 2: Rear Panel
LED Indicators on the switch: Color/Status Description No. of LED Amber On Power on Power Power Power off Green On Link Up Link / ACT Green Blinking Data is transmitting or receiving 10/100M No connection (Port 1~8) Amber On Port is linked to Power Device No Power Device is connected Rear Panel AC input (100~240 V/AC, 50~60 Hz) UL Safety... -
Page 3: Specifications
Specifications Ports Number of Ports 8 ports (Fast Ethernet 10/100BaseTX, IEEE 802.3at PSE) Performance MAC Address Buffer Memory 1.625 M bits Transmission Method Store and Forward 10BaseT Cat. 3, 4, 5 UTP/STP Transmission Media 100BaseTX Cat. 5 UTP/STP 100 Mbps port - 148,800 pps Filtering/Forwarding Rates 10 Mbps port - 14,880 pps Mechanical Characteristics... - Page 4 Standards and Regulatory IEEE-802.3at PoE+ / PSE IEEE 802.3 10BaseT Standards IEEE 802.3u 100BaseTX IEEE 802.3x Flow Control Regulatory CE, FCC Class A Note: Specifications are subject to change without prior notice. April 2, 2013...
