Elevator Pushrod; Main Landing Gear - THE WORLD MODELS 28% EXTRA 330L Instruction Manual

7

Elevator Pushrod

Screw
PM 4 x 50 mm
Nylon Inert Lock Nut
M4
Bottom View
8

Main Landing Gear

2
M4x16mm Socket Head Screw
4
Screw
PWA2.3x8mm
16
Screw
PWA2.6x8mm
4
4.1mm
Plastic Collar
3mm Set Screw
4.1mm Collar
4.1mm Collar
Wheel
PWA2.6x8mm
2
2
Collar
4.1mm
4
4.1mm Plastic Collar
2
Nylon Inert Lock Nut
M8
2
Aluminum Plate
M8 Nut
Wheel
Pant
1mm
Completed
1mm
PL4120250
Heavy Duty Horn
Bracket
M2 Nut
Heavy Duty
Clevis
Pushrod
Ø2.5x132mm
Socket Head Screw
M4x16mm
Bottom View
3mm
PWA2.3x8mm
Bottom View
P . 6
PM2x8mm
Heavy Duty Clevis
PA1.7x8mm
M4 Nylon Insert
Lock Nut
PM2x8mm
PA1.7x8mm
PM4x50mm
3mm
PWA2.3x8mm
