Continuity tests

Set up your multimeter as shown in the figure below to per-
form continuity tests. Press
test function (
The beeper will sound as a continuity indication. Press
switch between normal open (
contacts.
• Normal open: Circuit is normally open, the beeper will
sound when a short is detected.
• Normal close: Circuit is normally closed, the beeper will
sound when an open is detected.
3
2
Smart
The continuity function detects intermittent shorts and opens
NO TE
lasting as short as 1 ms. A brief short or open causes the multi-
meter to emit a short beep.
U1273A/U1273AX Quick Start Guide
U1273A/U1273AX Handheld Digital Multimeter
Performing Measurements and Tests
is shown on the display).
5
1
to switch to the continuity
) and normal close (
4
OFF
(open)
ON
(closed)
to
Dual
Exit
)
