When you activate the MOB function the following actions are
automatically performed:
• a MOB waypoint is created at the vessel's position
• the display switches to a zoomed chart panel, centered on the
vessel's position
• the system displays navigation information back to the MOB
waypoint
Multiple MOB waypoints are saved by repeatedly pressing the MOB
buttons. The vessel continues to show navigation information to
the initial MOB waypoint. Navigation to subsequent MOB waypoints
needs to be done manually.
Delete a MOB waypoint
1.
Select the MOB waypoint to activate it
2.
Select the MOB waypoint's pop-up to display the MOB waypoint
dialog
3.
Select the delete option in the dialog.
A MOB waypoint can also be deleted from the menu when it is
activated.

Screen capture

You need to turn on the Screen capture option in the System
Settings dialog to be able to take a screenshot on a touch screen.
When the function is activated, you can take a screenshot on a
touch screen by double-selecting the title bar of an open dialog, or
by double-selecting the status bar if no dialog is open.
To view files, refer to "Files" on page 145.
