Pro-Form GT 85X User Manual page 5

2. While another person lifts the rear of the Frame (1),
attach the Rear Stabilizer (14) to the Frame with two
M10 x 74mm Button Screws (33).
3. While another person holds the Upright (3) near the
Frame (1), connect the Upper Wire Harness (32) to the
Lower Wire Harness (31).
Gently pull the upper end of the Upper Wire Harness
(32) to remove the slack, and slide the Upright (3) onto
the Frame (1). Be careful to avoid pinching the Wire
Harnesses. Attach the Upright with three M10 x 20mm
Button Screws (35) and three M10 Split Washers (34).
4. Attach the Water Bottle Holder (29) to the Upright (3)
with two M4 x 22mm Screws (15).
5. The Console (6) requires four "D" batteries (not includ-
ed); alkaline batteries are recommended. Press the tab
on the battery cover and remove the battery cover.
Insert four batteries into the console; make sure that
the batteries are oriented as shown. Then, reattach
the battery cover.
2
3
3
35 34
1
4
3
5
5
14
1
33
Be careful to avoid
pinching the Wire
Harnesses (31, 32).
35
34
32
31
29
15
6
Batteries
Battery
Cover
Batteries
