SBC81872 Socket479 All-in-One CPU Card Series User's Manual
2.3

Connectors

The connectors allow the CPU card to connect with other parts
of the system. Some problems encountered by your system
may be a result from loose or improper connections. Ensure
that all connectors are in place and firmly attached. The
following table lists the function of each connector on the
SBC81872.
Connectors
ATX 5VSB power connector
System Fan1
System Fan2
ATX +12V power
LVDS LCD Channel B
LVDS LCD Channel A
Pallare IDE port
Floppy port
CPU Fan
General output panel
LCD power
USB 1,2
NOTE:
1.
SBC81872VE Lan is Realtek 8100C.
2. SBC81872V2G Lan1 and Lan2 are Broadcom BCM5721.
3. SBC81872VG Lan is Realtek 8110S
8
Label Connectors
CN1 COM1
CN2 COM2
CN3 Printer port
CN4 Serial ATA Channel 1
CN5 Serial ATA Channel 0
CN6 LAN2 RJ45
CN7 LAN1 RJ45
CN8 VGA function
CN9 Internal Mouse
CN10 Internal Keyboard
CN11 Mini PCI socket
CN12 External KB/MS (Mini
Din)
Jumpers and Connectors
Label
CN13
CN14
CN15
CN16
CN17
CN18
CN19
CN20
CN21
CN22
CN23
CN24
