Table of Contents

1
STEINDORFF
A. Features and Functions
Through optical enlargement, this comparison microscope, can help the user to observe
clearly, by looking into the same eyepiece set, the images in both the right and left imaging view
fields, and compare two or more objects effectively in cutting, joining or overlapping view fields.
Due to its powerful magnification, this instrument enables the user to perceive the differences
between very small similar objects.
Model NYMC0035000C Comparison Microscope is a new generation product of our long-
time experience and technical innovation. With our success in solving the technical problem of the
adjustability of its comparison line width, which has been listed as one of the national technical
secrets, its quality has, therefore, reached the international advanced standard.
Model NYMC0035000C is our improved product on Model NYMC0035000A. It not only
has all the technical properties of Model NYMC0035000A, but also offers better image quality
and higher magnification. With more illuminating modes, more attachments, better shape and
structure, it therefore performs a superior work.
This model is an ideal instrument for police stations, procuratorial organs and courthouses to
identify finger prints, shot marks, tool traces, seals and writings, and for colleges and universities
to use for educational purposes as well. It is also suitable for banks, archeological studies,
electronics researches, biological science and agriculture.
NYMC0035000C
Comparison Microscope

Operating Instructions

®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NYMC0035000C and is the answer not in the manual?

Questions and answers

Related Manuals for STEINDORFF NYMC0035000C

Summary of Contents for STEINDORFF NYMC0035000C

  • Page 1: Operating Instructions

    Due to its powerful magnification, this instrument enables the user to perceive the differences between very small similar objects. Model NYMC0035000C Comparison Microscope is a new generation product of our long- time experience and technical innovation. With our success in solving the technical problem of the adjustability of its comparison line width, which has been listed as one of the national technical secrets, its quality has, therefore, reached the international advanced standard.

  • Page 2: Main Technical Parameters

    ® STEINDORFF B. Main Technical Parameters eyepiece visual inspection photo-taking video-recording general magnifying power working interface interface magnification imaging view field distance 10X/Φ18 25X/Φ6..96 16X/Φ11* magnification (mm) 0.44X objective 0.64X 7.7X/Φ23.4 19.2X/Φ8.9 12.3X/Φ14.3 1.9X/12.6×18.9 bridge 1.0X 12X/Φ15 30X/Φ5.7 19.2X/Φ9.17 3X/8×12...
  • Page 3 ® STEINDORFF 1. video interface 19. level stage 2. photography interface 20. rotatable stage 3. eyepiece 21. power box 4. binocular head 22. luminescence lens 5. pull lever 23. light pipe 6. separation line knob 24. universal luminescence stand 7. bridge body 25.

  • Page 4: Function And Operation

    ® STEINDORFF 3. Remove the dust cover from the binocular head (4) and fit the wanted eyepiece in its place; 4. Plug one end of the power line into the socket on the base (13) and the other end into a socket of good grounding connected with a 220V power source.
  • Page 5 ® STEINDORFF dust cover, insert the screw driver that goes along with the machine into the groove within the bridge body and carefully regulate the line by watching through the eyepiece and turning the driver slightly until it shapes as is shown in Picture 4. If it is like the line in Picture 3, adjust the left screw.
  • Page 6 ® STEINDORFF the reticle scales cannot match respectively. In such cases, the user can slightly turn the right or left magnification handle (8) and the right objective magnification until all the scales match well. Picture 5 shows the right scales images of the right and left magnification reticles. The same procedure must be followed if the user changes the magnification of the objectives.

  • Page 7: Maintenance

    ® STEINDORFF correct position showing clearly both the comparison line and the target object. For the best recorded results, the user is supposed to refer to the various instructions of all the above mentioned parts for the correct adjustment. 8. Application of Polarized Light, Coaxial Light and Transillumination: Polarized light works better for the examination of traces like scratches.
  • Page 8 ® STEINDORFF 3. The user is not supposed to disassemble the instrument. In case of disorder, send it back to the producer for service.
